Hot Dipped Galvanized Cyclone Mesh Farm Gates Heavy Barred Welded Farm Gate 1.05x3.66m



1.Stockmaster Gate Specification:

  • 1.05m(H)x10'/11'/12'/13'/14'/15'.
  • 6 x 8mm diameter horizontal bars in a 25mm frame.
  • 25mm flat uprights with the unique Greyson twist for added strength.
  • 8mm diameter high-tensile horizontal bars pass through punched verticals welded for extra strength.
  • Entire gate hot-dip galvanised and hand fettled.

Benefits

  • Robust construction for extra strength.
  • Climb resistant.

fram gates .png

2.Vertical Bar Gate:

  • 1.0m (H)x3'6"/5'/6'/7'/8'/9'/10'/11'/12'/14'.
  • 25mm nominal bore pipe frame.
  • 7.5mm bar uprights at 100mm spacings.
  • Adjustable hinge 20mm clamps top and bottom.
  • Split link latch attachment.
  • Hot-dip galvanised.
  • Two one piece adjustable hinges, 50mm x 3mm flat formed and zinc electro plated.
  • Clamped with 1mm x 8mm x 40mm and 1mm x 8mm x 45mm bolt.

<br9M4(AYCOL15_8{W((6SF)9.png" width="544" height="415" ori-width="401" ori-height="306"/>

3.Chain-link Netting Gate:

  • 1.0m (H)x3'5"/5'/6'/7'/9'/10'/11'/12'/14'.
  • 25mm nominal bore pipe frame.
  • 75mm diamond mesh 3.15mm wire infill.
  • 25mm nomimal bore pipe support uprights.
  • Two weld-on hinges manufactured from heavy duty flat steel.
  • Split link latch attachment.
  • Hot-dip galvanised.


4.Deermaster Chainlink Gate:

  • 1.50m/1.88m (H)x10'/11'/12'/14'.
  • 25mm nominal bore pipe frame.
  • 75 x 75 x 3.15mm chainklink mesh.
  • 25mm nominal bore pipe internal frame.
  • Two welded on hinges made from heavy duty flat steel.
  • Split link latch attachment.
  • Hot-dip galvanised.


5.Barred Deer Gate:

  • 1.88m (H)x12'/14'.
  • 13 x 7mm horizontal bars.
  • Two weld on hinges manufactured from heavy duty flat steel.
  • 25mm nominal bore pipe frame.
  • Fully hot-dipped galvanised.


6.Mesh Farm Gate:

  • 1.15m (H)x6'/8'/10'/12'/14'.
  • The frame pipe are 25mm,32mm,40mm ect.
  • Infill tube are 20mm,25mm,32mm.
  • Mesh opening:200x100mm,250x75mm.
  • Wire diameter:4mm,5mm.
  • The pipes and mesh are hot-dipped galvanised.

 FG01 (2).png

7.More Types Farm Gate:



Company Information

Haotian Hardware Wire Mesh Products Co.,Ltd is located in " Hometown of wire mesh" wire mesh park of  Anping, Hebei.Our  company got the ISO 9001:2000 quality management system certification and SGSect. We always adhere to" selection better material, exquisite design, elaborate sophisticated  services " bussiness philosophy to strict management with high-quality products to offer customers ideal return. We sincerely hope that we can establish good trade relations with domestic an foreign clients in frank cooperation,mutual benefit and development.
