Горячеоцинкованные циклонные сетчатые фермерские ворота тяжелые сварные 1 05x3 66

Описание и отзывы

Характеристики

Hot Dipped Galvanized Cyclone Mesh Farm Gates Heavy Barred Welded Farm Gate 1.05x3.66m

1.Stockmaster Gate Specification:

• 1.05m(H)x10'/11'/12'/13'/14'/15'.
• 6 x 8mm diameter horizontal bars in a 25mm frame.
• 25mm flat uprights with the unique Greyson twist for added strength.
• 8mm diameter high-tensile horizontal bars pass through punched verticals welded for extra strength.
• Entire gate hot-dip galvanised and hand fettled.

Benefits

• Robust construction for extra strength.
• Climb resistant.

2.Vertical Bar Gate:

• 1.0m (H)x3'6"/5'/6'/7'/8'/9'/10'/11'/12'/14'.
• 25mm nominal bore pipe frame.
• 7.5mm bar uprights at 100mm spacings.
• Adjustable hinge 20mm clamps top and bottom.
• Split link latch attachment.
• Hot-dip galvanised.
• Two one piece adjustable hinges, 50mm x 3mm flat formed and zinc electro plated.
• Clamped with 1mm x 8mm x 40mm and 1mm x 8mm x 45mm bolt.

9M4(AYCOL15_8{W((6SF)9.png" width="544" height="415" ori-width="401" ori-height="306"/>

3.Chain-link Netting Gate:

• 1.0m (H)x3'5"/5'/6'/7'/9'/10'/11'/12'/14'.
• 25mm nominal bore pipe frame.
• 75mm diamond mesh 3.15mm wire infill.
• 25mm nomimal bore pipe support uprights.
• Two weld-on hinges manufactured from heavy duty flat steel.
• Split link latch attachment.
• Hot-dip galvanised.

4.Deermaster Chainlink Gate:

• 1.50m/1.88m (H)x10'/11'/12'/14'.
• 25mm nominal bore pipe frame.
• 75 x 75 x 3.15mm chainklink mesh.
• 25mm nominal bore pipe internal frame.
• Two welded on hinges made from heavy duty flat steel.
• Split link latch attachment.
• Hot-dip galvanised.

5.Barred Deer Gate:

• 1.88m (H)x12'/14'.
• 13 x 7mm horizontal bars.
• Two weld on hinges manufactured from heavy duty flat steel.
• 25mm nominal bore pipe frame.
• Fully hot-dipped galvanised.

6.Mesh Farm Gate:

• 1.15m (H)x6'/8'/10'/12'/14'.
• The frame pipe are 25mm,32mm,40mm ect.
• Infill tube are 20mm,25mm,32mm.
• Mesh opening:200x100mm,250x75mm.
• Wire diameter:4mm,5mm.
• The pipes and mesh are hot-dipped galvanised.

7.More Types Farm Gate:
