Product name: hand chain hoist, outdoor event stage hoist
1.Chain block is a manual ,portable,easily operated lifting appliance . It is especially suitable for lifting work in the open air and places where power is not available .
2.Safe and reliable to use ,convenient to maintain .
3.High efficiency and small pulling force
4.Light weight and portable in size .
5.Attractive appearance ,small size
6.Durable
Model | HSZ-0.5 | HSZ-1 | HSZ-1.5 | HSZ-2 | HSZ-3 | HSZ-5 | HSZ-10 | HSZ-20 | |
Lifting weight (ton) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | |
Standard lifting height meters | 2.5 | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 | |
Test load tons | 0.75 | 1.5 | 2.25 | 3 | 4.5 | 7.5 | 12.5 | 25 | |
Two hook falls the small distance (mm) | 270 | 270 | 368 | 444 | 486 | 616 | 700 | 1000 | |
Bracelet tension when loaded with Newton | 225 | 309 | 343 | 314 | 343 | 383 | 392 | 392 | |
Lifting chain rows | 1 | 1 | 1 | 2 | 2 | 2 | 4 | 8 | |
Lifting chain round steel in diameter(mm) | 6 | 6 | 8 | 6 | 8 | 10 | 10 | 10 | |
The main size( mm) | A | 120 | 142 | 178 | 142 | 178 | 210 | 358 | 580 |
B | 108 | 122 | 139 | 122 | 139 | 162 | 162 | 189 | |
C | 24 | 28 | 34 | 34 | 38 | 48 | 64 | 82 | |
D | 120 | 142 | 178 | 142 | 178 | 210 | 210 | 210 | |
The net weight kg | 9.5 | 10 | 16 | 14 | 24 | 36 | 68 | 155 | |
Packing gross weight kg | 12 | 13 | 20 | 17 | 28 | 45 | 83 | 193 | |
Packing size (length x width x height) | 28×21 | 30×24 | 34×29 | 33×25 | 38×30 | 45×35 | 62×50 | 70×46 | |
Lifting height every increase 1 m increase | 1.7 | 1.7 | 2.3 | 2.5 | 3.7 | 5.3 | 9.7 | 19.4 | |
