CBB80 1Polypropylene пленочные конденсаторы освещения используемые для осветительных приборов

Описание и отзывы

Характеристики

Product name

 CBB80-1Polypropylene film capacitors lighting used for lighting fixtures

Product Description

  CBB80-1Polypropylene film capacitors lighting used for lighting fixtures

   1. Type: Plastic case wire type with stud.

   2. Capacitor features and uses:

       High temperature plastic housing or the use of light, the internal structure of device discharge resistors

       and fused, The capacitor has advantages of low dissipation, hight insulation resistance, good self-healing           character, and steady electricity performance, anti-striking current, strong over-carrying capacity, etc.

        Used in high and low pressure sodium lamp, mercury lamp, metal halide lamp, since the role of power                  factor compensation.

   3. Capacitor technical parameter:

        Rated voltage: 250VAC

        Rated frequency: 50/60HZ

        Capacitance range: 2uf-120uf

        Capacitance deviation: +/-5%

        Reference standard: IEC61048 IEC61049 EN61048 EN61049 UL810

        Climatic category: 40/85/21

        Capacitance tolerance: +/-5%

        Certificate: VDE TUV CQC UL ISO IMQ

Sample

   CBB80-1Polypropylene film capacitors lighting used for lighting fixtures

     1. Samples free if customer bear the courier cost

     2. Samples time: please check with service person if you need samples.

Advantage/Innovation

 CBB80-1 Polypropylene film capacitors lighting used for lighting fixtures

  1. Our products have UL, TUV, VDE, CQC, ISO, IMQ certificate.

  2. All products through strict quality inspection, it's 100% inspect in semi-finished products and

      finished products.

  3. All products are made in destless workshop.

  4. Quickly delivery time.

Outline Drawings and Size

  Size for some speci. for reference:

 Package information

 Packing information for some speci. for reference
