Моно ротор для винтовой насос или прогрессирует полости насоса ротора

Описание и отзывы

Характеристики

Product Name:

#Rotor #Stator #Coupling ro d#Drive shaft #Rubber sheath #Coupling rod pin #Shaft pin #Holding band #Retaining sleeve #Rubber ring #Shaft seals #Steel ring#

Introduction of screw pump stator

1 The stator is a screw sleeve with more than one threaded head of the rotor.

2 The stator is one of the main wear parts of single screw pump. The stator will be worn because of the solid composition, pressure and viscosity of the conveying medium and the rotation of the rotor.

The stator surface is worn, will cause the rotor and the stator no longer has the seal, the stator must replace promptly.

3 Coordination and shape of stator and rotoris the main performance parameters of the pump.

4 The stator material has a variety of options, there are a variety of natural and synthetic elastic rubber materials, including natural rubber, nitrile rubber, EPDM rubber, FKM, etc., can provide special materials for harsh work conditions also

Brief introduction of the main material of stator

For different mediums, there’re different rubber formulations to choose, such as wear resistant, corrosion resistant and heat resisting

Rubber Materials Details

1)One of the most important parts is the stator in screw pump, the high quality of the stator is determined by the vulcanization process of the rubber.

2)Strict control of raw materials selection, strict control of the mixing process and the final analysis in the laboratory, to ensure the high quality of products and long service life.

3)In a close cooperation with our customers we define the properties of the material to fulfill the customers demand. In addition, based on our long-term experience in plastic injection, concerned about the safety of production and reduce c

osts, and the results are compared to ordinary products, we have a better performance of the selected material solutions.

Tubes Material:

1)The stator tube options include low carbon steel and stainless steel ,

2)Special materials: 316L, 904L, and CD4MCu dual phase stainless steel ,which can operate at temperatures as high as 150 degrees


The material of stator my company commonly used:

Rubber: NBR;  EPDM;  FPM;  SI

Stator shell: Q235; SUS304; SUS316L

Introduction of screw pump rotor

1The center part of the screw pump is composed of rotor and stator. Screw rotors are usually made of metallic materials and are made into unique twist angles through special cutting machines. A special structure consisting of a steel rotor and an elastic stator makes it capable of conveying materials containing solid particles.

2 The rotor is placed in the stator, sealed together in a helical structure. When the rotor rotates, the internal continuity of the stator is running, the liquid in the closed space runs continuously, conveying out from the suction side of the "No pulsation" and "quantitative" transmission.The outer thread and the thread of the rotor are made according to the special processing;

Material of rotor

Carbon steel, stainless steel, SS304, SS316L,904L etc.

The material of rotor my company commonly used: 40Cr, Cr12mov,SS304, SS316L, 2205 and 904L

The introduction of screw pump coupling rod

1.The connecting Rod Group consists of connecting rod, universal joint,coupling rod, guide bush, rubber rings, and a rubber sheath, connecting rod pin, retaining sleeve,steel wire rings, drive shaft, etc.

2 The connecting Rod Group is in addition to withstanding not only the force of drive shaft, but also to bear the force of its own swinging longitudinal and transverse, the size and direction of these forces are cyclical, so the connecting rods are subjected to alternating loads such as compression and stretching.The size and direction of these forces are cyclical, so the connecting rods are subjected to force of compression, stretching and so on.

3 The coupling rod must have sufficient fatigue strength and structural stiffness. If the fatigue strength is insufficient, it will lead to break the connecting rod body or connecting rod interface, and then produce the major accident whole machine damage.

4 If the rigidity of the connecting rod is not enough, it will cause the bending deformation of the rod body and the universal joint, resulting in the eccentric grinding of the coupling rod, guide bush, thecoupling rod bush, etc.

Function of connecting rod:

The connecting rod is used to connect the drive shaft and the rotor , and transmit the actuator force to the rotor, thus driving the rotor to rotate the motion. According to the requirements of the media, the joint shaft can be installed with a broken bridge aid flow device

Material of connecting rod:

The main damage form of the connecting rod is fatigue fracture and excessive deformation. Generally, the fatigue fracture area is three high stress areas on the connecting rod. The working condition of the connecting rod requires that the connecting rod has high strength and anti-fatigue performance, and it also requires sufficient rigidity and toughness. Traditionally, the materials used in the process of connecting rod are 304, 316L, 40Cr, 2Cr13, 2205, 904L and so on.

Introduction of drive shaft

1. Drive shaft is the part for connecting and assembling various accessories, and turning cylindrical object parts.

2. The drive shaft is composed of a shaft tube, rubber sheath, seal and a universal joint .

3.The screw pump drive shaft is the drive power transmission to the coupling rod, thus driving the rotor rotation. Several components are connected by a universal joint or a flexible shaft.

4.The drive shaft material has 304, 316L, 40Cr, 2Cr13, 2205, 904L, also needs to make the adjustment qualityor surface treatment of hard chromium .

The material of drive shaft we commonly used:

SUS304 ; 304, 316L, 40Cr, 2Cr13, 2205, 904L

Screw pump drive shaft common sense:

1.The overall layout of the screw pump determines the dimensions of the drive shaft and their range of change. If the drive shaft is damaged, worn, deformed, and loses its dynamic balance, will cause abnormal sound and vibration in the running screw pump,When serious, it can cause the related parts to be damaged,So the rationality of the drive shaft design will directly affect lifetime of universal joint assembly and drive shaft, and efficiency of universal drive and stability of screw pump operation

2.To usedrive shafts along with different drive products, the surrounding work environment is more complex, such as temperature, humidity, water, steam, dust, sand, oil, acid, alkali, corrosive medium, saline, radiation and other conditions, these are important factors to be considered when selecting the drive shaft

3. The drive shaft is a rotating body with a high rotational speed and less support, it’s dynamic balance is very important.In general, the drive shaft before the factory to carry out a dynamic balancing test, need to adjust on the balance machine.

There are 6 major functions of the drive shaft

1. Improve the rotor and its composition of product quality;

2. Reduce noise;

3. Reduce vibration;

4. Improve the support components (such as the joint shaft, coupling, universal Joint Assembly) life;

5.Reduce the user's discomfort;

6.Reduce the power consumption of the product;

Detailed introduction of rubber sheath

Characteristics and performanceof rubber sheath

1.Good abrasion resistance, strong tearing resistance, bending strength;

2. High tensile strength and elongation of fracture;

3. High temperature tolerance (-30 degrees ~+120 degree);

4.The hardness adjustable range is big (Shaw 60a-95a);

5.Compression permanent deformation rate is low;

6.Oil-resistant corrosion resistance, good solvent resistance, high mechanical strength, long service life and other characteristics;

7.Ozone-resistant anti-aging is especially good;

8.Non-toxic,environmental

2. Material

NBR, EPDM,FPM, SI. The FPM is particularly suitable for the use of strong acid, alkali, corrosive chemicals and high speed environment, and the temperature is 30 degrees and 160degrees

The material of rubber sheath we commonly used:

NBR, EPDM, FPM.

3.Custom and design

Have stock with the standard size, thenon-standard size andspecial rubber shaped pieces can be customized;

Special products can customize according to the pattern, welcome consultation and order

Mechanical Seal

Mechanical Seal: Mg1/mg12/mg13

Brand: STD Seals

Application: screw pump, chemical pump, water pump, impurity pump

Applicable industries: smelting, papermaking, refining, fine chemicals, sewage treatment, etc.

Product Features:

Sealing surface: Graphite, cemented carbide, SIC, etc.

Auxiliary seals: nitrile, ethylene propylene, fluorine gum, etc.

Metal components: 304, 316L, etc.

Structural features: Single end face, unbalanced, arbitrary rotation, rubber corrugated pipe

Working Parameters:

Spec.: 10-100mm

Pressure: ≤1mpa

Temperature: -20℃~150℃

Line speed: ≤10m/s

Suitable for medium: sewage, oil and weak corrosive medium

Note:

Mechanical seals precision parts, in the installation process, avoid smashing and bangingseal  components!

Non-assembly mechanical seals

1. To assemble mechanical seal static component into the pump cavity gland.

2. When the mechanical seal using V-ring structure, in the installation of special attention to its V-shaped openings must face the medium (or sealing fluid) pressure direction.

3.The mechanical seal components set on the pump shaft (also must make the V-type openings facing the pressure direction) according to the model specification to determine the position of the spring seat and according to the requirements of the adjustment, so that the spring pressure to meet the design requirements. thus ensuring the normal working pressure of the sealing surface. Tighten the screws evenly.

4.The installation of one-way rotation (that is, the loop or hook spring transmission) mechanical seals, especially attention to the spring rotation, its rotation should be the same as the axis rotation direction, so that the spring more tightly. From the mechanical seal to the end of the static ring to see, to determine the rotation direction of the axis, clockwise direction for the right, counterclockwise direction for the left rotation

Second, operation and precautions

1. Mechanical seals was absolutely not allowed dry turn ,the pump must be fully vented before the device starts, so that the media is filled with sealed cavities before the device can be opened.

2. The operation of equipment should strictly follow the following procedures:

3. Before the equipment operation, should start flushing water, 5 minutes later, start the mainframe;

4. If you do not open flushing water, will lead to sealing surface dry friction, high temperature, seal ring burnout and seal ring coking, which will lead to complete failure of the seal. The phenomenon is more prominent in the two-terminal and multi-faceted structures.

5. In the operation of equipment, should always check whether the flushing water is unblocked, pressure to meet the requirements;During operation, flushing water cannot be interrupted or stopped.

6. Tthe best way to operate the pump is continuous work,If you must stop, you should rinse the backflow sediments from the pipes and pump cavities.If the equipment is to be stopped, it must be shut down for 5 minutes before the flushing water can be turned off.

Screw pump Holding ring Detailed

(1)product name: steel holding band stainless or holding ring

(2)the product use: it is used for rubber sheath is locked and fixed on the shaft coupling rod and the drive shaft.

(3)product material: stainless steel

Main material description of holding band:

Stainless steel

The main alloying elements in stainless steel is Cr , only when the Cr content reaches a certain number, the steel is corrosion resistance . Therefore, the stainless steel general Cr (chromium) content is 10.5% at least. Stainless steel also contains Ni, Ti, Mn, N, Nb, Mo, Si, Cu and other elements. Stainless steel corrosion resistance decreases with the increase of carbon content, therefore, the majority of stainless steel carbon content is lower, the maximum is not more than 1.2%, some steel Wc (carbon content) or even less than 0.03% (such as 00Cr12).

The material of  Holding Band  my company commonly used :

SUS304;  SUS316L

Standard factory availability

1)There are all kinds of accessories in the  STANDARD’s factry, we offer a fast turnaround to help reduce the downtime of  equipment, you don’t need to have a lot of inventory.

2)For the spare parts, can be quickly shipped,  to ensure that the production won’t be interrupted or reduced to the minimum downtime. With good service and very competitive price, customer can earn time an profit from the cooperation with us.

Highly competitive pricing

During customers become more and more focused on running and maintaining costs,in evaluating the conservation and efficiency of factory, we need to consider priority the price and supply capacity of spare parts.

International excellent brand screw pump parts supply

Standard use their own expertise, manufacturing capabilities and channels to provide the world's major brands ( NE-----,SE----, MO--,and so on) a full range of screw pump parts, these accessories performance is good, rugged, durable, including: stator, rotor, transmission shaft, joint shaft, PIN, or a complete set of rotating parts, etc.

We can provide the universal spare parts of NE------ brand

We can provide the universal spare parts of SE---- brand

We can provide the universal spare parts of MO-- brand

1) What products does Standard offer ?

Standard offers screw pump, Screw pump accessories, and the global solution of the fluid system product.

The product range summary of Standard

Progressive cavity pumps for conveying and metering low to highly viscous media with or without solids

Macerators for macerating solid and fibrous components in the medium

Control systems for monitoring, regulating and controlling processes

Services: consulting, commissioning, maintenance, NE-----, SE----, and MO-- Universal Spare parts, repairs and various service contracts

2) Does Standard supply custom-made pumps ?

 Yes, Standard screw pumps and spare parts as well as other brands (NE-----, SE----, MO--) Universal accessories can be ordered online. For order please contact us ( WhatsApp/ Wechat/ Telephone: 0086 189 4242 4342 )

3) Can Standard spare parts be ordered online ?

Yes, Standard screw pumps and spare parts as well as other brands (NE-----, SE-----, MO--) Universal accessories can be ordered online. For order please contact us ( WhatsApp/ Wechat/ Telephone: 0086 189 4242 4342 )

4) How fast can my Standard pump be delivered ?

Normally, standard pumps are delivered in 4 to 6 weeks. In urgent cases, delivery times between 2  to 5 days may be possible. Please contact us ( WhatsApp/ Wechat/ Telephone: 0086 189 4242 4342 )

Our services :

1) Our screw pump series products, reasonable price, quality service, provide quality inspection. Welcome to sample Custom-made.

2) we have a special quality Supervision Department to ensure the quality of mass production.

3) If the product has quality problems, we will deal with the first time, find out the cause, take responsibility.

4) If you are interested in our products and companies, please leave a message or email us, we will give you an answer with in 24 hours

Why choose us ?

1) Factory Direct Sales, no intermediate links, competitive price

2) Our machines are imported from Europe, the original machine factory, the production of stable product quality, do not use low quality equipment.

3) Ensure on-time delivery, procurement, we can provide the best quality of service control, transportation, documentation and so on.

4) We provide samples and OEM services.

5) We will reply to your enquiry within 24 hours.

6) More than 20 years of experience in this industry business, and professional team, so that our customers feel relaxed and comfortable working with us in

7) Please contact us by email and we will send you more pictures for more choices of our products.
