Product Description
Zhejiang 50 liters electric Stainless Steel homogenizing double jacketed blending kettle for fondant in confectionery industry
Usage:
the machine is widely used in food processing, such as: candy(soft candy, hard candy), cakes, beverages, preserves, canned food etc, also can be used in large restaurants or canteens to make soups, stews, stews, porridge etc.
It is a good equipment to improve quality, shorten time and improve working conditions in food processing.
the machine is widely used in food processing, such as: candy(soft candy, hard candy), cakes, beverages, preserves, canned food etc, also can be used in large restaurants or canteens to make soups, stews, stews, porridge etc.
It is a good equipment to improve quality, shorten time and improve working conditions in food processing.
Features:
our machine could use electricity as heat source, optional steam or gas .
Electric heating type adopt putting electric heating rods, electric thermocouples and heat-conducting oil in interlayer, heating product indirect through heating heat-conducting oil, in standard the highest temperature up to 150C(more over should use higher boiling point heat-conducting oil), all of them are controlled by electric control box.
Electric heating type adopt putting electric heating rods, electric thermocouples and heat-conducting oil in interlayer, heating product indirect through heating heat-conducting oil, in standard the highest temperature up to 150C(more over should use higher boiling point heat-conducting oil), all of them are controlled by electric control box.
It has the characteristics of large heating area, high thermal efficiency, uniform heating, short boiling time of liquid, and easy control of heating temperature.
The inner pot body (inner pot) of the pot is made of acid-resistant and heat-resistant austenitic stainless steel, equipped with a thermometer and an electric control box(steam heating is optional pressure gauge, a safety valve ).
The equipment is beautiful, easy to install, easy to operate, and reliable in insulation performance.
The inner pot body (inner pot) of the pot is made of acid-resistant and heat-resistant austenitic stainless steel, equipped with a thermometer and an electric control box(steam heating is optional pressure gauge, a safety valve ).
The equipment is beautiful, easy to install, easy to operate, and reliable in insulation performance.
Model | Volume Diameter×Height | Form | Pressure(mpa) | slope angel | Inlet&Outlet | Motor Power / Heating Power |
JCG-50 | 50 60×45 | Tilting Stirring | 0.3 | 90° | 1/2” | 0.75kw/8kw |
JCG-100 | 100 70×50 | Tilting Stirring Fixed | 0.3 | 90° | 3/4” | 0.75kw/12kw |
JCG-200 | 200 80×55 | Tilting Stirring Fixed | 0.3 | 90° | 3/4” | 1.5kw/15kw |
JCG-300 | 300 90×65 | Tilting Stirring Fixed | 0.3 | 90° | 3/4” | 1.5kw/15kw |
JCG-400 | 400 100×75 | Tilting Stirring Fixed | 0.3 | 90° | 3/4” | 1.5kw/18kw |
JCG-500 | 500 110×85 | Tilting Stirring Fixed | 0.3 | 90° | 1” | 2.2kw/18kw |
JCG-600 | 600 120×95 | Tilting Stirring Fixed | 0.3 | 90° | 1” | 2.2kw/24kw |
JCG-1000 | 1000 1400×115 | Tilting Stirring Fixed | 0.3 | 90° | 1” | 3.7kw/30kw |
Detailed Images
Quality stainless steel
Contact parts of machine are completely made of food grade stainless steel 304/316L, meeting the standard of GMP.
Motor device
1. Pure copper motor: low noise, stable dynamic, sustainable work.
2. Taiwan GPG motor and reducer
3. Dismountable engine base
Flat cover /Shell cover
1. Flat cover with double open lids /Shell cover with man hole
2. Creative handle, quick to open, convenient for production
Inlet port
1. Available port connection: Clamp, Thread Butt weld, Flange etc.
2. Flange process arc transition smooth, easy to clean no dead ends, beautiful appearance.
Stirring device
adopt Import PTFE material scraper blade, easy to clean and disassemble, few dead angle, prevent viscous material from adhering on the wall.
Swiveling mechanism
standard configuration, worm wheel and worm are cast iron; SS304 can be Optional. Bracket adopt stainless steel.
Tilting type Discharge hole
adopt Half round design, easy to discharging and no dead angle.
Sight glass
tempered glass material, flange connection form.
Vent valve
exhaust jacket air, avoid cause much pressure in jacket.
SUS electric control box
1. intelligent temperature controller, SUS304 box
2. split type PT100 thermal resistance
3. Germany Schneider Electric Components
Electric heating:
the interlayer is provided with electric heating rods.
Full Stainless steel small oil cup
be provided for filling Conduction oil, tilting with kettle body; adopt 102 pipe diameter, easy use and difficult outflow.
Drain valve
Ball valve, can get rid of extra water inside interlining
Full steel base
Can withstand greater pressure, stable work
Electrical heated tube(electric heating rods):
1. adopt threaded connection form, convenient assembly.
2. pad adopt Import Teflon material, Resistant to 300 degrees temperature, difficult to leak.
Related Products
Certifications
Packing & Delivery
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in plywood case or carton package for small parts.
If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T in advance, 30% as deposit, and finish 70% balance payment before delivery.
We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 3 to 4 weeks after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
Q6.Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Our Service
Please contact our After-sales service department in time within 30days after you received the cargo. | ||
Tel: 86-577-86821328 Time: 9:00 a.m.- 6:00 p.m. (Beijing time) | ||
Process | Please provide the copy of Sales Contract and describe the problems appeared. | |
Problems confrimation: | ||
Slight problem: | Please send the proof to our After-Sales Department, we will reply within two days. | |
Serious problem: | ||
a | We will dispatch our Quality and Problems Appraisers to make a confirmation. | |
b | Have a negotiation of the compensation and sign agreements | |
c | Our After-Sales Department will perform the duties as the agreements | |
Our Company
Zhejiang L＆B Fluid Equipment co., Ltd
a modern enterprise which combine the ability of design, development, manufacturing, engineering, installation, technical services, has special technology to design and exploit by CAD software and computer and is a outstanding leader among valve fields.
We have advanced CNC lathes imported from Japan.We can manufacture the valves and fitting according to ISO, DIN, IDF, SMS, 3A, while we can produce the products per as the requirement from the clients(non-standard).
We are specialized in producing different kinds of valves, pipe fitting, tubes, manhole covers, pumps, tanks etc for many years. We can design the products according to your special request. OEM is welcome too.
