Product Description









MJ376-S Series CNC Precise Horizontal Band Sawing Machine
        ---------The ideal one for cutting rose wood


With features of high precise cutting and outturn percentage, good surface finish, easy and automatic operation, MJ376-S series CNC precise horizontal band sawing machine is the best one for cutting rare rosewood and hard wood.





click to view the video




Technical parameters:



























































































Specification’s Items



MJ376-S-600



MJ376-S-900



Max. wood diameter



600mm



900mm



Saw wheel diameter



654mm



720mm



Max. sawing height



550mm



900mm



Max. sawing width



600mm



900mm



Blade speed: ordinary wood standard speed



850 r/min



850 r/min



Max. sawing length



4000mm



4000mm



Power output of electric motor (380V,50Hz,3phase)



17.55kw



21.05kw



Main motor power



15kw



18.5kw



Lifting motor power



1.05 kw



1.05kw



Forward and backward motor power



0.75 kwx2



0.75 kwx2



Forward speed



14m/mim



14m/mim



Backward speed



14m/min



14m/min



The size of saw blade



5080×34×0.9mm



6144×50×0.9mm



Rail length (standard model)



6000mm



6000mm



The overall dimensions



6000×2300×2300mm



6000×2735×2700mm



Total weight



2300kg



3500kg








 Advantages:
1. High Precision:
High precise cutting and stable operation ensures the error of working thickness less than 0.2mm.



2. Good Surface Finish:
With stable running, good planeness, and high-quality tungsten steel blade, this handsaw
can simultaneously realize functions of cutting, planning and directly sanding.



3. High Outturn Percentage:
High precise cutting, short sawing distance, good surface finish, combining with function of cutting and planning, this horizontal band saw can reduce the prepared size of panel thickness during the cutting process, getting one more sheet from cutting each 10 panels.



4. Easy and Automatic Operation, Great Savings in Labor
It is easy to operate with computer operation interface. Without professional sawing, grinding and blade repair workers, common workers can easily to learn and skillfully to operate. The band saw just operated by only one worker, can automatically and continuously complete a one-time sawing processing, saving a lot of labor and money.



Performance Characteristics:
1. This Band saw has PLC program, LCD touch screen and computer control interface.



2. High precise machining with imported linear guideway and ball screw



Stable and smooth running with imported servo motor drive and programmed control



3. Safety and environmental protection with one-step realization of automatically cooling, lubrication, and dust extraction



4. With high safety performance, the whole sawing process is automatic, safe and reliable



5. It is convenient to assemble, debug, and move with appropriate structure and small covering area



6. It realizes automatic blade grinding and filing with MF115 saw sharpening machine













More Products











































































1. All the prices are FOB Shanghai. Include packing charge;


2. Payment Terms:  T/T 30% as deposit after signing contract, and 70% before shipment;


3. Delivery Time:  Within 30 days after receiving the deposit.
