section cutting easy operation cnc vmc

Product Description

Type

Unit

716

X-axis travel

mm

1000

Y-axis travel

mm

600

Z-axis travel

mm

600

Travel between spindle nose to worktable

mm

170-770

Travel between spindle center to worktable

mm

600

Length of work table

mm

1300×600

Max.loading capacity of worktable

kg

1000

Table T-solt

mm

5-18

Spindle taper



BT40

Spindle speed

r/min

60-6000

Power of motor(spindle)

kw

7.5/11

Motor of motor(three axises)

kw

2

Max.moving speed of X

m/min

16

Max.moving speed of Y

m/min

16

Max.moving speed of Z

m/min

12

Style of handle



BT40

CNC system

FANUC 0i MD

Position accuracy

mm

0.01/500

Repeatability position accuracy

mm

0.005

Net weight

kg

8000

Pressure requirement

kg/cm²

6

Power supply

kg

20

Machine dimensions(L×W×H)

mm

3120x2290x3000mm

5 3

  Difference

1, CNC milling machine and machining center for the completion of a larger amount of milling of the product processing;
2, CNC engraving machine for a smaller amount of milling or light metal processing.
From the perspective of CNC machine tools used by the machine:
1, CNC milling machine and machining center of the CNC system requirements: stable and reliable, operation, easy maintenance;
2, CNC engraving machine most of the use of enterprise independent research and development or outsourcing of industrial controllers.
From the axis of the machine power and spindle speed point of view:
1, CNC milling machine and machining center of the shaft power is relatively large, the spindle power is relatively large.
2, CNC engraving machine most of the use of low-power motor.

Packaging
♦ Packaging details: inner plastic, outer plywood case
♦ Delivery detail: 15-20 days afterpayment


Minimum order quality: 1 set

Port: Shanghai or any Chinese port

Payment Method: L/C, T/T, Western Union, MoneyGram
Supply Ability: 200 sets/month
Warranty period: 12 months
Company profile

Jiangsu Sanxing Machinery Manufacture Co.,Itd was founded in 1993. The company is a high-tech enterprise integrating research and development, production and sales. Our company has been awarded IS09001-2008 international quality certificate CE certificated for Europe, and also honored with "enterprise of high-tech". Our many products are titled “high—tech products” and “provincial famous trademark”, get the Machinery Industrial Science And Technology Award and theSmall&Medium Enterprises Innovation Award of the Ministry of Science and Technology, meanwhile, the products own 3 invention patents, 27 New practical patents, 3 designing patents and 7 patents during application.
