Class leading power to weight ratio and performance. The DY1150 is the flagship offering from Taian loaders. Thanks to a powerful 50 hp perkins diesel engine, the DY1150 is capable to lift up to 1600KGS. It comes standard equipped with a 82 l/min hydraulic system with electric control and a multi-functions joystick, delivering unrivaled performance in any conditions or terrain.
With its innovative design, comfort and stability, the DY1150 is the ideal machine for professionals building firms, municipalities, tourist facilities and rental companies. Reduce labour cost and increase output by working smarter
------For all our loaders, we offer one year or 1000 working hours warranty whichever comes first.
Product
If your day involves pallet-stacking, bale-moving, or other repetitive functions, take a look at the new Return-To-Position/Electronic-Self-Leveling feature, available with select H Series Loaders and 6R Series Tractors. You can set up to two boom positions and two bucket or fork positions; a quick tap of the loader joystick returns the boom and/or bucket to your preset position. And for operators who need a self-leveling loader without additional mechanical or hydraulic components, take a look
Every Taian wheel loader has hydraulic quick attach incorporated more than 30 attachments.
The Taian hook hitch enables quick coupling and decoupling from the cabin with extra safety inside.
Over 30 tools turn your Taian articulated loader into a productive workhorse able to do any job.
The list includes a 4-in-1, standard buckets, pallet forks, augers, trenchers, rotary hoes, mower, grab buckets and much more.
Don't buy a loader that just does one job, buy one that is built to do the lot and get even more productivity day in, day out.
Taian articulated loaders are boosting productivity in mining, earthmoving, construction, local councils, horticulture and landscaping and many other industries.
The versatility of over 30 attachments allows Taian articulated loaders to be adapted for almost any task. Why buy a machine for every job when your Taian articulated loader can become a power plant to quickly do just about any job?
Model | DY1150 |
Max. length | 3410 mm |
Max. width | 1510 mm |
Max. height | 2320 mm |
Max. reach(boom extended) | 3540mm |
Max. reach(boom retracted) | 2910mm |
Bucket capacity | 600L |
Rated loading capacity | 1600kg |
Tipping load | 2600kg |
Min. turning radius | 2818mm |
Ground clearance | 330mm |
Turning angle | 450 |
Speed | 16.5 km/h |
Weight | 2010 kg |
Standard tire | 31X15.5-15 |
Tire pressure | 2.8 bar |
Oil tank capacity | 70L |
Pressure | 200bar |
Working oil flow | 82L/min |
Tracking oil flow | 117L/min |
Oil model(mineral oil) | L-HL46 |
Engine brand | Yanmar |
Number of cylinder | 4 |
Cooling system | Water cooling |
Rated power | 36.5 Kw |
Rotation speed | 2600 r/min |
Fuel tank capacity | 32L |
Battery capacity | 70Ah |
Voltage | 12v |
OPTIONS | |
Closed cabin with door | |
Heating Systerm | |
Rear hydraulic output | |
Collapsible Roll Bar | |
Trailer hook | |
3 point hitch |
Small gaden farming tractors DY 1150 agricultural machinery ----hydraulic rear output
Small gaden farming tractors DY 1150 agricultural machinery with different
We are professional manufacturer for wheel loader,and we have enough experience for business and service.welcome to visit us.
Customer visits the factory:
Customer feedback:
FAQ:
Q: Why choose us?
A: We are real manufacturer, compared with other trading companies, the quality, delivery time and after service can be well guaranteed.
We has advanced production technology and management team, and we are well capable in offering overseas after-sales service. Besides, we also provide rational packing and shipping program,let shipment cheaper and security.
Q: What’s the warranty of the products?
A: For all our loaders, we offer one year or 1000 working hours warranty whichever comes first. And most important, within warranty, we’ll offer relative parts for free by airway or express post, customers can receive the parts within 4~6 days.
