TMK Ni-MH 24V D size 10000mAh battery specification | |
Model | TMK- D1000 * 20 |
Dimension | Length:224mm; width: 96mm; height: 60mm. |
Nominal Voltage | 24V |
Nominal Capacity | 10000mAh |
Minimum capacity | 9000mAh |
Internal Resistance | <300mΩ |
Discharge Cut-off Voltage | 20.0V |
Maximum Charge Voltage | 29.0V |
Standard Charge Current | 0.1C for 15 hours |
Standard Discharge Current | 0.2C |
Weight | App. 3600 g |
Working temperature | Charge: 0℃~+45℃ |
Discharge: -20℃~+50℃ | |
Storage temperature | 0 ℃~ +25℃ |
Cycle life | Over 1000 cycles |
1. High energy density (W/kg), about 50% better than NiCad’s.
2. Typical cycle life is 3000 cycles; can be deep cycled (80% to 100% DOD).
3. NiMH batteries also tolerate over charge and over discharge conditions and this simplifies the battery management requirements.
4. Wide operating temperature range (-40℃~+85℃).
5. Environmentally friendly (No Cadmium, Mercury or Lead).
6. Much safer than Lithium based cells in case of an accident or abuse due to the use of more benign active chemicals, a particularly important property in high power and automotive applications.
(1). Your inquiry related to our products or prices will be replied in 24 hours.
(2). Experienced staffs to answer all your enquires in fluent English.
(3). We can do the OEM and ODM service.
(4). Protection of your sales area, ideas of design and all your private information.
(5). No matter big order or small order, we will provide all the best quality, best service.
(6). Our products have 12 months warranty.
(7). If our products have any problem, we will send free in the next order if it is our mistake.
Paper box, paper carton, or as your request; OEM brand packing boxes or product labels, free design service are available.
Within 10-15 working days after receipt of payment.
