KODI SZG Model Low Temperature Double Cone Rotary Vacuum Drier

1. Double Cone Vacuum Drier /  Rotary Cone Vacuum Drier/ Rotary Vacuum Drier
2. Easy to operate and control
2. GMP standard
3. High efficiency

The Rotary Cone Vacuum Drier consists of a jacketed double conical shell rotating around 6 RPM with under the state of vacuum inside the shell, pass steam or hot water in to jacket for heating. The large heating surface area presented by the internals of the cone ensures uniform drying of the product, as the product gently tumbles while the cone rotates slowly. The vaporized steam can be pumped out through vacuum exhaust pipe when the damp raw material absorbed heat. The diffusive action induced by the tumbling cone constantly presents a fresh layer to come into contact with the indirectly heated walls of the shell, the dry speed of raw material is quickened and uniform drying efficiency is raised too. A well designed sealing system enable maintenance of deep vacuum inside the shell, and also ensures positive circulation of a heating media in the jacket.




Features of Double Cone Rotary Vacuum Drier

• Design is GMP


• All Product contact parts AISI 316/ 316L & non-contact parts AISI 304. Or completely 304.


• Simple & compact Design for Easy to operate, clean, convenient & user friendly.


• Automated mixing and Drying process in single bowl.


• Dust free operation.


• High vacuum operation


• Low temperature drying.


• Solvent recovery


• Continuous rotation of container, material will make complex impacting motion in the container and reach to uniform mixing and drying at low temperature..


• Continues vacuum maintenance during process.


• Vacuumed closed system with condenser, Receiver for solvent recovery & Cyclone separator to recovery the solid particle.


• Rapid & Complete discharge / Zero holdup after discharge


• The product dried is homogeneous with uniform properties.


• Very low value of final moisture even at low drying temperatures.


• Inside Filter assembly with 5 Micron.

Applications of Double Cone Rotary Vacuum Drier

1. Material that cannot undertake high temperature.

2. Material that is easy to oxidize.

3. Material that do not permit to destruct.

4. To recover material with residual volatile.

5. Material with vigorous irrelative and toxicity.

6. Biology products and mine.

7. Dry raw materials of pharmaceutical industry, chemical industry, foodstuff industry, dyestuff industry and biochemistry at low temp etc.

Technical Parameter of Double Rotary Cone Vacuum Drier

Successful Experience Overseas By KODI Double Cone Rotary Vacuum Drier

•


  International high quality certification product chain





•


  Manufacturer, more reasonable price





•


  Solid technical support and after-sales service





•


  Uphold the principle of “Customer Supreme”( Balance payment after equipments run normally)





•


  Exports to more than 20 countries and regions, good customers feedback





•


  One-stop service, customized exclusive project feasibility report




Changzhou KODI Machinery Co., Ltd. located in the birthplace of China drying equipment----Zhenglu Industrial Park, Changzhou City, Jiangsu Province which is 150km away from Shanghai city, with a comfortable environment and convenient transportation access.

KODI company is a professional manufacture of drying machine, which include Seaweed processing machine, Seaweed drying machine (Cottonii to carrageenan, Agar agar ), Spray dryer, Food ingredients spray dryer, Flavor spray dryer (Cocoa, Maltdextrin,Gum Acacia), Lab Spray dryer, Industrial Vacuum Dryer, Double Cone Vacuum Drier / Rotary Cone Vacuum Drier / Rotary Vacuum Drier, Gelatin processing machinery, Gelatin drying machine (Hide and bone),Gelatin production line. we also deal in high-quality fermentation tank, Bright tank , Extraction tank, concentration tank , evaporator and etc.

We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment. Our products conform to international standards, such as CE, SGS.

KODI company also has a lot of top talent which have more than 15years of work experience, include research, design, manufacture and after sale service. Our products sell to all of the world (such as Australia, Malaysia, Indonesia, Vietnam, Philippines, Korea, Brazil, Chile, Peru, Argentina, Russia, Ukraine, South Africa, Cameroon, Sudan, Syria) and also have the good cooperation with the foreign client and vendor.

We are sure that our high quality products and excellent services will be appreciated by the growing list of satisfied customers. Contacting us is the first step to build a long and successful business relationship with us. Welcome!




Sale service
1. Ensure product with high quality and pre-commissioning before delivery;
2. Delivery on time;
3.Provide full set of documents as customer’s requirements.

After-sale service
Provide considerate services to minimize clients’ worries.
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3.Train the first-line operators;
4. Examine the equipment;
5.Take initiative to eliminate the troubles rapidly;
6.Provide technical support;
7.Establish long-term and friendly relationship.

Service commitment
1. Provide clients one-year warranty to make sure the machine work well;
2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;
3.Send every client a preferential quotation.

           In order to quota you the right Double Cone vacuum drier / Rotary Cone Vacuum Drier / Rotary Vacuum Drier, we would like to get the following information include in your inquiry:

•


  -What is the raw material?  Material related characteristic? Does it corrosive, strong basicity, or highly acid? Please confirm.





•


  -What is the capacity per hour you need (kg/h)?





•


  -What is the initial moisture and final moisture of finished products you require to get?





•


  -What about the maximum heat temperature of raw material?





•


  -What kind of fuel you use to heat the dryer? Natural gas, electricity, fuel oil or steam?





•


  -Which equipment material do you like prefer? SUS304, SUS316L or Carbon steel?





•


  -Provide us your country’s electricity information, such as phases, voltage, HZ?





•


  -How about dust collect requirements?





•


  -Other special requirements?
