Плоская Солнечная Тепловая панель 200 Вт 25 лет гарантии

Сохранить в закладки 60620073201:


Цена:0,21 $ - 0,22 $*

Количество:

  • В избранное

Описание и отзывы

Характеристики





 13


Green power, Green World.





SOLAR PANEL / PV MODULE:



1. Use A-grade solar cell with high efficiency;
2. High transmittance, low iron tempered glass with enhanced stiffness and impact resistance;
3. Anodized aluminum alloy frame with high mechanical strength for easy installation;
4. Anti-aging EVA and high flame resistant Back Sheet (TPT), to provide long-life and enhanced cell performance;
5. Outstanding electrical performance under high temperature and low irradiance conditions;
6. 100% apply EL(electroluminescence) technology;
7. 5 years limited warranty, 10 years limited warranty for 90% power output, 25 years limited warranty for 80% power output;
8. With CE, ISO9001: 2008 certificate;



































































Electrical Characteristics

STC (Irradiance 1,000W/m2, module temperature 25℃, AM=1.5)OL200M-10
Rated Power (Pmax)                                         200W
Voltage at Pmax (Vmp)
18.1V
Current at Pmax (Imp)
11.05A
Warranted Minimum Pmax 100W
Short-Circuit Current (Isc) 11.99A
Open-Circuit Voltage (Voc) 21.6V
Module Efficiency19.00%
Operating Module Temperature-40℃ to + 85℃
Maximum System Voltage1,000V(IEC) / 1,000V(UL)
Maximum Series Fuse Rating15A
Maximum Reverse Current20.25A
Power Tolerance0 ~ +5 W




05


FAQ:


1Q: Do you have your own factory?


   A: Yes, we do. Our loctation is in Yuyao city, Zhejiang province.


2. Q: How can I visit your factory?


  A: Please let us konw bofore you go there. We will arrange time to pick you up and show you around.


3. Q: Do you provide free sample?


    A: Usually we do not provide free sample.


4. Q: Could you print our company LOGO on the nameplate and package?


   A: Yes, we can.


5. Q: Do you accept custom design on size?


   A: Yes, if the size is feasible.


6. Q: How do you overcome the anti-dumping and countervailing duties?


   A: We can use original Yuyao solar cells, and provide Certificate of Origin of Yuyao


7. Q: How can I be your agent in my country?


   A: Please leave feedback. It's better for us to talk about details by email.


8. Q: Do you have solar project engineer who can guide me to install system?


   A: Yes, we have a professional engineer team. They can teach you how to install a solar system.


PS:Our factory can produce all kinds of solar panels and solar moudles according to customers' needs.
