Тестер толщины геотекстиля ISO 9863

Сохранить в закладки 60621566787:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики


Application

HY2110 Geotextile Thickness Tester is used to determine the thickness of geotextile material and related products under different pressure and specified time.

HY2110 Geotextile Thickness Tester .jpg

Standard

ISO 9863

ASTM D5199

GB/T 13761

JTG E50





Note: This Geotextile Thickness Tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.

Features

1.         Mechanical structure, simple and easy to operate

2.         Digital dial gauge, easy to read, 0~24mm±0.01mm or 0~1±0.001mm optional

3.         Main parts are made of stainless steel

4.         With different press weights, users can select suitable one to test

Specification



Model

HY2110

Geotextile Thickness Tester

Press foot area

25cm(diamter: Φ56.42mm )

Sample pressure

2±0.01kpa

20±0.1kPa

200±0.1kPa

Measure range

0~12±0.001mm

Dimensions

730×320×350mm

Weight

40kg



-







 3456789
