Transport Network Equipment PTN 1900 PTN190 F Supports 40GE PTN1900
- Категория: >>>
- Поставщик: Shenzhen Uonel Technology Co. Ltd.
Сохранить в закладки 60670921493:
Описание и отзывы
Характеристики
Product Description
Transport Network Equipment PTN 1900 PTN190-F Supports 40GE PTN1900
OptiX PTN 1900 NEs are the new generation of multi-service chassis-shaped devices applicable to the aggregation layer on packet transport networks. OptiX PTN 1900 NEs support 40GE bandwidth aggregation, adaptable to various application scenarios. They provide device- and network-level protection and reliably aggregate and forward traffic.
Product Features
High-Bandwidth Aggregation:
- Supports the 80 Gbit/s capacity and 40GE high-bandwidth interfaces, which aggregate high-bandwidth services.
- Supports Circuit Emulation over Packet (CEP) interfaces used to aggregate VIP VC4 private line services.
- Supports various types of interface, such as E1, FE, GE, STM-1, and STM-4 interfaces.
Storing Environment Adaptability:
- Uses a subrack with the depth of 300 mm (11.81 in.), which is applicable to an ETSI cabinet with the depth of 300 mm (11.81 in.).
- Provides a heat dissipation system with better performance and minimized noise.
- Has low power supply consumption and supports two 63 A power supply modules.
High Reliability:
- Provides high-reliability device-level 1+1 redundancy protection for main control boards, cross-connect boards, and power supply modules, which ensures that the device is running stably.
- Supports various network-level protection functions, such as dual homing, virtual private network (VPN) fast reroute (FRR), and label switched path (LSP) automatic protection switching (APS), to reliably forward services.
- Supports various network-level protection functions, such as dual homing, virtual private network (VPN) fast reroute (FRR), and label switched path (LSP) automatic protection switching (APS), to reliably forward services.
- Supports operation, administration and maintenance (OAM) mechanisms, such as Y.1731 and Multiprotocol Label Switching Transport Profile (MPLS-TP), which rapidly detect fault and monitor device performance
Specifications
| Item | PTN 1900 | |||
|---|---|---|---|---|
| Subrack dimensions (H x W x D) | 220 mm x 436 mm x 295 mm (8.66 in. x 17.17 in. x 11.61 in.) | |||
| Fully loaded subrack weight | 15 kg (33.08 lb) | |||
| Working voltage | -38.4 V to -72.0 V | |||
| Standard power consumption | 190 W | |||
| Switching capacity | 80 Gbit/s | |||
| Number of slots | 7 slots: 2 slots for main control boards 5 slots for service boards | |||
| Environment requirements | Long-term working temperature: 0°C (32°F) to 50°C (122°F); short-term working temperature: -5°C (23°F) to 55°C (131°F); storage temperature: -40°C (40°F) to 70°C (158°F); relative humidity: 5% RH to 95% RH; altitude ≤4000 m | |||
| Interface capacity of the equipment | E1: 160 ATM STM-1: 40 Channelized STM-1: 48 STM-1/STM-4 POS: 10 FE electrical port: 60 FE optical port: 40 GE electrical port: 14 GE optical port: 22 10GE: 4 | |||
| Service types | E-Line, E-LAN, L3VPN, CES, and ATM | |||
| Service protection | LMSP, LAG, LSP APS, MC-PW APS, ring protection, VRRP, MC-LAG, IP FRR, and VPN FRR | |||
| Clock synchronization | External clock, IEEE 1588v2, synchronous Ethernet, and TDM clock synchronization | |||
| HQoS | Five-level QoS scheduling and traffic shaping | |||
| MPLS | RSVP-TE, LDP, and static LSPs | |||
| OAM | Y.1731, MPLS-TP, birdirectional forwarding detection (BFD), 802.1ag, 802.3ah, link-state pass through (LPT), and pseudo random binary sequence (PRBS) | |||
| Alarms and performance monitoring | Supported | |||
| Security | 802.1x and user authentication | |||
Delivery
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
| Delivery Options | Estimated Delivery Time |
|---|---|
 | 3-5 business days |
 Fedex | 3-5 business days |
 By Sea | 10-20 business days |
Notice:
Above mentioned information are just for your reference only,we will keep you posted for the tracking delivery schedule.There are two delivery options available for by air and by sea:
Deliver to port:
Uonel is responsible for transporting goods to port. All subsequent customs and transportation fees are the
responsibility of the buyer. Uonel will recommend trustworthy local freight forwarders to you.Uonel can facilitate the progress under buyer's permission and at buyer's expense.
Deliver to door:
Uonel will quote all destination charge prior once we have confirmed order.
Uonel is responsible for transporting goods to door after you have made the payment.
Warranty
100% Low Price Guarantee:
Uonel provides high-quality products at low wholesale prices
100% Quality Assurance:
All items are ORIGINAL NEW and GENUINE only.
Free Technical Support:
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee:
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment:
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed product: 1 Year
The Support Contacts:
If your products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Company Profile
Uonel is one of the biggest Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.Our company have more than $5million products in stock.
Most of our technical engineers had work exprience in company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
