marine Search and Rescue Radar Transponder SART

Model : ESR-06



Product Description : Radar SART is a device enforced to be equipped on the vessel by IMO. The function complies with GMDSS requirement and relevant international standards , owing whole independent intellectual property .



Main Parameters :

Operation Frequency : 9200 MHZ ~ 9500MHZ

Polarization Mode : Horizontal Polarization

Antenna : Horizontal beam ( omni-direction )  Less than +/2 dB ; Vertical beam : +/- 12.5 dB

Transmitter :

scanning speed ( Right way side- rising ) : 7.5 +/- 1 us ;

Reverse recovering : 0.4 +/- 0.1 us

Radiation power : >= 27dBm

Response delay : <= 0.5us



Receiver :

Effective sensitivity : <= 52dBm

Recovering time : <= 10us

Operation Temperature : -20 degree ~ + 55 degree .
