Двухчастотная метка UHF NFC EM4423 RFID с защитой от бренда

 1. IC Feature of EM4423 Passive RFID Label:

EM4423 is a new dual frequency chip with NFC and UHF functions,with 2 frequencies, the security will be much higher,also the label can be read by near distance and long distance.

NFC interface

ISO/IEC 14443A -3 compliant tag

 NFC Forum Type 2 compatible

 Enables NDEF data structure configurations

 Communication baud rates at 106kbps

 7 byte unique ID number using same serialization as EPC interface

 1920-bit user’s memory

 Anti-tearing support for NFC capability container (CC) and Static/Dynamic lock bytes

 NFC Memory locking mechanism per block/page

 ACCESS counter increased at first reading

 Optional read-only locking function

Optional limit of unsuccessful LOGINs

 Optional security timeout for unsuccessful LOGINs

 Optional control of EPC privacy features

 UHF power detection

 17pF or 50pF NFC on-chip resonant capacitor

EPC interface

 ISO/IEC 18000-63 compliant

EPC Gen2 V2 compliant

- Alteration EAS compliant

- Tag Alteration (Core) compliant

 Supports multi-vendor chip-based serialization

 128-bit or 224-bit UII/EPC encodings

96-bit TID using same serialization as NFC

interface

 160-bit or 64-bit USER memory

 32-bit Access and Kill passwords

 Fast writing using the BlockWrite command

 Block permalock for USER memory

NFC field detection

 NFC ACCESS counter is readable

2. Basic info of EM4423 Passive RFID Label:

3. EM4423 Passive RFID Label Main solutions:

Variable Data processes:

a: Color Pre-printed
b: Barocde Pre-printed
c: QR Pre-printed
d: RFID programming
e: Individual package sort by SKU
f: Black position line printing etc

All package requirement could be customize by your side, Please share us what's your request?

Or, Here is some normal package details for your reference:

1. Sealing style at end of each roll: Sticky tape (no trace) or Binding by paper tie for optional.
2. Tail: 1m leading silicon paper at the beginning and the end of roll or customize by your side.
3. Connet Joints: Normally for two joints (excluding the joints generated by blank spaces begin and end),
Also you can advice your specified standard?
4. Package: ESD Package box.
5. Paper Tube: inner diameter of 3 inches
