Mini refrigerator cold freezer transport truck Refrigerated Box Vans for sale
Product features:
Refrigerated truck is closed van used to transport the frozen or fresh goods,and is also kind of special
transportation vehicle equipped with refrigeration unit device and polyurethane thermal insulation box.
Transportation category:
Often transport frozen food like beef, dairy products,seafood,fruits and vegetables, vaccine and drug.
Construction:
Chassis,insulation box body,refrigeration unit,temperature recorders in the carriage,for special
purpose,optional parts including meat hook,aluminum alloy rail,ventilation channel and others.
Refrigeration unit classification:
Non-independent refrigeration unit,independent unit,the domestic units and imported units.Usually using
external refrigerator for a few mini refrigerated truck.
Choice for insulated body:
Choose the newest PU foam insulated material,"Sandwich structure" with FRP or stainless steel inside and outside panels to keep good thermal insulation property and light weight,at the same time the whole refrigerated boxes look clean and beautiful.
Technical parameters of refrigerator freezer truck
Technical Parameters : Mini Freezer Truck | |||
Dimensions (mm) | 4599x1720x2455 | Container size(mm) | 2795x1545x1535 |
Engine type | Gasoline LJ469Q-1AE9 | Wheel base(mm) | 3070 |
Gear box | MR513B | Rear axle | 102 Intubation type hydraulic brake |
Tyre | 175R14 | Vehicle frame(mm) | 100x65x25 |
Chassis Brand | Foton Jiatu | Leaf Spring Number | 5 |
Total mass | 2545kg | Load Capacity | 795kg |
Curb Weight | 1620kg | Compressor | can be choose |
Temp | 0~-15 | Container material | Glass fiber reinforced plastics and Lined polystyrene |
Emmission Standard | Euro 4 | Other requirements | can be choose |
The chiller truck is commonly used to transport the frozen food, dairy products, vegetable and fruit and vaccine medicine etc.
For the special requirements of freezer vehicle,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots, ladder, LED lamp, etc. parts can be chosen and installed. Different refrigerated units are available like Carrier, Thermos King, Dongin, Kingtec, etc. The standby battery, side door, side windows, etc are optional.
We provide various chiller vans with capacities ranging from 0.5MT to 60MT:
Packaging & Shipping: Nude with waxing by roro ship or bulk ship or use container.
Payment terms: 30% deposit by T/T, before leaving factory must pay the 70% balance by T/T.
Hubei Chengli Special Automobile Manufacturing Co,. ltd. is located in the China special automobile industry city-Suizhou, Hubei Province. The company is the first domestic private enterprise entering the special automobile industry, which is also the first pressure tank vehicle manufacturing private enterprise and got the quarantine license from General Administration of Quality Supervision of China. The company has focused on all kinds of special automobile R&D, manufacturing, sales and service. Chengli Special is a high-tech enterprise in Hubei province and has passed the certification of ISO9001, ISO16949, GJB9001 and CCC authentication of automobile products.
Our main product
1. Factory direct supply: reliable quality and fast delivery;
2. Warranty; from the date of receiving, in normal use within 30000kh or within one year, we will repair for free, but the wearing parts and electrical parts are not included. After one year, we only charge cost when the question occurs;
3. Tracking service: lifelong
4. Chassis question: when the question occurs, please find the local nearest Service Station for repair or maintenance, or call us if the local have no Chassis Service Station;
5. Spare Parts: Superstructure spare parts is sent by ourselves, we only charge cost; Chassis spare parts is sent by the local Service station, if the local have no chassis service station, please call us freely.
6. OEM Ability: We can customize the truck according to your request, such as material, size, color, paint, logo, etc.
7. Warm tip: please operate, use, and maintain the truck according to our manuals and Instructions. When the question occurs, please call us freely.
1.You are factory or trading Company?
We are oversea sales department of Chengli automobile. You are welcomed to visit our factory.
2.Could your company modify the standard product depends on my request?
Yes. Our company is specialized in researching and designing various of special purpose vehicle and spare parts. We can provide the product that meet with your personalized demand.
3. Could your company totally customize products for me?
We can provide the customized-designing product meeting with any of your demand.
4. Could you provide certification that we need?
We can provide various certifications associate with trailer and truck. Such as DOT, ADR, SASO and so on.
5. How about the after-sale service?
We can provide you the technical support to guide you repaire your product. And we will also send original spare parts free of charge by air. If you have special need, we can let our engineer to help you in person.
