NS XY400 01 китайский производитель точных линейных нанопозиционирования xy flexure PZT стек стадий

we can customize any models products according to your sizes or quality requirements

Nanometer displacement system has come into more and more extensive use, such as AFM (atomic force microscope), precision optical equipment, semiconductor device, and various high-tech industries. Nanometer displacement system is capable of generating and measuring displacement superior to nanometer (nm) and the entire system consists of three parts, i.e. nanometer displacement platform, controller and control software.

As a mechanical device, nanometer positioning platform is equipped with one or several piezoelectric ceramics internally which generate monaxial or multiaxial motion. The nanometer positioning platform designed and manufactured by us applies flexible hinge which connects the motion unit with the fixed base. The nanometer positioning platform is equipped with a built-in high-precision sensor. When under closed-loop control, our sensor technology may bring about resolution ratio in nanometers and sub-nanometers when the linearity is guaranteed.

The controller supplies power to the nanometer positioning platform. When under closed-loop control, the controller in the nanometer positioning platform provides displacement data for the controller. Besides, the controller processes the displacement data and corrects the output voltage signals periodically to make sure the displacement data and the instruction data are consistent.

Simple and convenient software

The nanometer displacement system usually serves as a component for large devices. Therefore, the proper application of nanometer displacement system with other hardware is of great importance. There are multiple modes of communication between our controller and the external environment. The one most commonly used is to control the displacement of the nanometer displacement platform via BNC signals (-10V~10V). It is also acceptable to accomplish the communication with controller by means of USB port and digital IO. The software inside controller achieves the PID algorithm-based closed-loop control for notching filter and integrates the waveform generator with sine wave, square wave and triangular wave internally. In case of special requirements from customers, we may offer customized software and controller firmware.

We not only manufacture the nanopostioning stages or mircopositioning stages , we also provide the precision position control solutions for clients , here are our successful cases for our valued clients .

CASE 1:

Sample rotation axis: beating 6 m, resolution 0.0005 degrees, repeatability accuracy 0.001 degrees

Sample size: diameter 150mm, length 1.2m, maximum weight 100kg.

X ray source moving stage: stroke 1.5m

The utility model is suitable for the horizontal helical scanning control system of various types of cores, such as ores, cores, etc. the utility model has the characteristics of large load, large size, and high precision helical scanning

CASE 2:

3-axis sample table: Travel 20 * 100 * 100, resolution 50nm.

Scanning rotating stage : stroke 360 degrees, resolution 0.0001 degrees, accuracy 0.003 degrees, beating: 4 m, medium hole diameter 175mm.

Detector switching platform: Travel 300mm, resolution 50nm, repeatability: 0.5 m.

Other positioning stages : stroke 150mm, repeatability 2 mu m

Suitable for various power X ray scanning, internal imaging systems, and other high-precision optical scanning system
