Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply


Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply


Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply



Product Description



Features:


  • Mean Well 36V DC Power Supply

  • Universal AC input / Full range

  • Built-in active PFC function, PF>0.95

  • High efficiency up to 89.5%

  • Withstand 300VAC surge input for 5 seconds

  • Protections: Short circuit / Overload / Over voltage / Over temperature

  • Built-in constant current limiting circuit

  • Built-in cooling fan ON-OFF control

  • Built-in DC OK signal

  • Built-in remote sense function

  • 5 years warranty


Model Series:











HRP-450-3.3 / HRP-450-5 / HRP-450-7.5 / HRP-450-12 / HRP-450-15 / HRP-450-24 / HRP-450-36 / HRP-450-48








Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply




Details:















































































































































































































MODELHRP-450-3.3HRP-450-5HRP-450-7.5HRP-450-12
OUTPUTDC VOLTAGE3.3V5V7.5V12V
RATED CURRENT90A90A60A37.5A
CURRENT RANGE0 ~ 90A 0 ~ 90A0 ~ 60A 0 ~ 37.5A
RATED POWER297W450W450W450W
RIPPLE & NOISE 80mVp-p80mVp-p100mVp-p120mVp-p
VOLTAGE ADJ. RANGE2.8 ~ 3.8V4.3 ~ 5.8V6.8 ~ 9V10.2 ~ 13.8V
VOLTAGE TOLERANCE   ±2.0%±2.0%±2.0%±1.0%
LINE REGULATION    ±0.5%±0.5%±0.5%±0.3%
LOAD REGULATION  ±1.0%±1.0%±1.0%±0.5%
SETUP, RISE TIME    1000ms, 100ms/230VAC          2500ms, 100ms/115VAC at full load
HOLD UP TIME 16ms/230VAC          16ms/115VAC at full load
INPUTVOLTAGE RANGE            85 ~ 264VAC         120 ~ 370VDC
FREQUENCY RANGE47 ~ 63Hz
POWER FACTOR PF>0.95/230VAC          PF>0.99/115VAC at full load
EFFICIENCY 80%83%87%88%
AC CURRENT 5A/115VAC        2.4A/230VAC
INRUSH CURRENT35A/115VAC          70A/230VAC
LEAKAGE CURRENT<1.5mA / 240VAC
PROTECTIONOVER LOAD105 ~ 135% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE3.96 ~ 4.62V6 ~ 7V9.4 ~ 10.9V14.4 ~ 16.8V
Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE 90°C ± 5°C (70°C ± 5°C 5V only) (TSW1 : detect on heatsink of power transistor) ;90°C ± 5°C (TSW2 : detect on heatsink of power doide)
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
FUNCTIONDC OK SIGNALPSU turns on : 3.3 ~ 5.6V ; PSU turns off : 0 ~ 1V
FAN CONTROL Load 20±10% or RTH2 ≥50°C  Fan on
ENVIRONMENTWORKING TEMP.-40 ~ +70°C (Refer to derating curve)
WORKING HUMIDITY20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY-40 ~ +85°C , 10 ~ 95% RH
TEMP. COEFFICIENT±0.03%/°C (0~50°C)
VIBRATION10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
SAFETY & EMCSAFETY STANDARDS U60950-1, TUV EN60950-1 approved
WITHSTAND VOLTAGEI/P-O/P:3KVAC     I/P-FG:1.5KVAC     O/P-FG:0.5KVAC
ISOLATION RESISTANCEI/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C / 70% RH
EMC EMISSIONCompliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3
EMC IMMUNITYCompliance to EN61000-4-2,3,4,5,6,8,11,EN55024 , EN61000-6-2, heavy industry level, criteria A ,
OTHERSMTBF139.9K hrs min.  MIL-HDBK-217F (25°C )
DIMENSION218*105*41mm (L*W*H)
PACKING1.19Kg; 12pcs/15.3Kg/0.82CUFT
















































































































































































































MODELHRP-450-15HRP-450-24HRP-450-36HRP-450-48
OUTPUTDC VOLTAGE15V24V36V48V
RATED CURRENT30A18.8A12.5A9.5A
CURRENT RANGE0 ~ 30A 0 ~ 18.8A0 ~ 12.5A 0 ~ 9.5A
RATED POWER450W451.2W450W456W
RIPPLE & NOISE 150mVp-p150mVp-p240mVp-p240mVp-p
VOLTAGE ADJ. RANGE13.5 ~ 18V21.6 ~ 28.8V28.8 ~ 39.6V40.8 ~ 55.2V
VOLTAGE TOLERANCE   ±1.0%±1.0%±1.0%±1.0%
LINE REGULATION    ±0.3%±0.2%±0.2%±0.2%
LOAD REGULATION  ±0.5%±0.5%±0.5%±0.5%
SETUP, RISE TIME    1000ms, 100ms/230VAC          2500ms, 100ms/115VAC at full load
HOLD UP TIME 16ms/230VAC          16ms/115VAC at full load
INPUTVOLTAGE RANGE            85 ~ 264VAC         120 ~ 370VDC
FREQUENCY RANGE47 ~ 63Hz
POWER FACTOR PF>0.95/230VAC          PF>0.99/115VAC at full load
EFFICIENCY 89%88%89%90%
AC CURRENT 5A/115VAC        2.4A/230VAC
INRUSH CURRENT35A/115VAC          70A/230VAC
LEAKAGE CURRENT<1.5mA / 240VAC
PROTECTIONOVER LOAD105 ~ 135% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE18.8 ~ 21.8V30 ~ 34.8V41.4 ~ 48.6V57.6 ~ 67.2V
Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE 90°C ± 5°C (70°C ± 5°C 5V only) (TSW1 : detect on heatsink of power transistor) ;90°C ± 5°C (TSW2 : detect on heatsink of power doide)
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
FUNCTIONDC OK SIGNALPSU turns on : 3.3 ~ 5.6V ; PSU turns off : 0 ~ 1V
FAN CONTROL Load 20±10% or RTH2 ≥50°C  Fan on
ENVIRONMENTWORKING TEMP.-40 ~ +70°C (Refer to derating curve)
WORKING HUMIDITY20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY-40 ~ +85°C , 10 ~ 95% RH
TEMP. COEFFICIENT±0.03%/°C (0~50°C)
VIBRATION10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
SAFETY & EMCSAFETY STANDARDS U60950-1, TUV EN60950-1 approved
WITHSTAND VOLTAGEI/P-O/P:3KVAC     I/P-FG:1.5KVAC     O/P-FG:0.5KVAC
ISOLATION RESISTANCEI/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C / 70% RH
EMC EMISSIONCompliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3
EMC IMMUNITYCompliance to EN61000-4-2,3,4,5,6,8,11,EN55024 , EN61000-6-2, heavy industry level, criteria A ,
OTHERSMTBF139.9K hrs min.  MIL-HDBK-217F (25°C )
DIMENSION218*105*41mm (L*W*H)
PACKING1.19Kg; 12pcs/15.3Kg/0.82CUFT





Mechanical Specification:



Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply




Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply




FAQ


Q1. Are you original Mean Well Power Supply ?
A: Yes, We sell 100% Genuine Mean Well, the Serial No. can be checked in Meanwell website.
Q2. Can I have a sample order firstly?
A: Yes, sample order is acceptable. Welcome to inquiry.
Q3. What about the lead time?
A: Sample order within 3 days, Bulk order for common type need 3~7 days, Not common type need 15~35 days


    after payment.
Q4. Do you have any MOQ limit ?
A: No MOQ limit, you can buy the quantity you need.
Q5. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, FedEx, UPS, or TNT. And it usually takes 3-5 days to arrive.
    For bulk order, Airline and Sea shipping also optional.
Q6. How to proceed an order ?
A: 1. Inquiry: Tell us your requirements, such as model No, Quantity and delivery address...
     2. Quotation: We will quote you soon according to your requirements.
     3. Confirmation: If quotation is OK, we will make PI for your payment.
     4. Payment: After your payment, please give us your bank slip, then we can arrange goods for you soon.
     5. Delivery: Once get your payment and goods all ready, we will delivery goods soon, and tell your the


     tracking number or Vessel No.
Q7: What's your payment terms?
A: We accept pay via T/T in advance, Paypal and Western Union
Q8: Do you offer guarantee for the products?
A: Yes, we offer 2-7 years warranty to our products.





Packing


Packing:


Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply


Shipping:


Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply





Factory View


Strict, professional production and test, large stock for fast shipping.


Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply








Certifications


What Certification do we have?


Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply





Application


What our Power Supply can do for you?


Meanwell HRP-450-36 Switch PSU 450W 36V DC Power Supply
