TF 1 - 11,INLINE Threaded filters, TF1 TF2 TF3 TF4 TF5 TF6 TF7 TF8 TF9 TF10 TF11

Compressed Air Filters

For over 40 years, Pneumatech has provided complete filtration solutions to protect your investment in equipment and processes. Our comprehensive line-up of filters is based on unique and proprietary enhanced media to efficiently reduce all types of contamination. We are proud to continue our legacy with this newest line of enhanced filtration systems and replacement elements - all in stock and ready to ship.

Filter Solutions

Pneumatech offers you a comprehensive line-up of innovative filter solutions to meet your specific needs. Our filtration solutions are engineered cost-effectively to provide the best air quality and meet today’s increasing quality demands.

For general applications we provide oil coalescing, particulate and oil vapor filters in a wide range of flows and pressures. Pneumatech is also your partner for breathing air, silicone-free,

sterile & process filtration.

Filter Grades

• P - Coalescing and particulate general purpose pre-filter
• G - Coalescing filters for general purpose protection, removing solid particles and oil aerosol
• C - High performance coalescing filters for general purpose protection removing solid particles and oil aerosol
• S - Particulate filters for dust protection, removing solid particles
• D - High performance particulate filters for dust protection, removing solid particles
• V - Oil vapor and odor removal filter

Use Pneumatech filters to

·  Protect and increase the efficiency of your Pneumatech refrigerant and desiccant air dryers

·  Remove oil and solid particles from the compressed air network at the source

·  Protect sensitive instruments and pneumatic equipment from contamination

Assured air purity

When compressed air comes into direct or indirect contact with your product, a much higher level of contaminant control is required. Particular attention needs to be given to contaminants that might appear during the compression and distribution of the air.

Pneumatech filters have been fully tested and qualified according to the latest ISO8573 and ISO12500 standards. Tests have been conducted in-house as well as in external labs; and are independantly validated by TÜV.

The innovative technologies behind our filters

• Enhanced high-performance stainless steel filter cores ensure ultimate strength and low risk of implosion
• New, enhanced media ensure high filter efficiency, low pressure drop and guaranteed lifetime performance
• Dust filter – with a large particulate capacity which prolongs filter lifetime
• Filter elements have been designed to guarantee proper sealing
• Ease of use with push-on element

·        2 product lines: Standard and High Efficiency

·        Pneumatech offers a Standard (S) range and a High Efficiency (HE) range of compressed air filters to best meet your process needs. Both filter ranges offer similar benefits such as:
- Maximum contanimant removal
- Energy savings
- Increased reliability
- Easy maintenance

The HE range is engineered for minimal pressure drops and offers significant energy savings over time. Pneumatech filters are available in a number of grades (P, G, C, S, D & V) and sizes.

FF 1 - 12 - Flanged Filters

Features & Benefits

Guaranteed air purity

• High-efficient glass fiber and foam media

No risks of:

• Cracked filter media

• Cylinder implosion

• Top cap leakages

• Oil re-entrainment

Significant energy savings

• Optimal filter media selection allows low pressure losses

• Zero-loss electronic drain included as standard

Highest quality standards

• In-house research, development & production

• Each filter subjected to rigorous quality control

• Fully tested and qualified according to ISO standards

Robust design

• Stainless steel cores guarantee ultimate strength

• Protection paper to avoid damaging of glass fiber media

• Special coating ensures high corrosion protection, and therefore a housing lifetime of at least 20 years

Easy service and installation

• Bottom cover with special rotating system

• Different grade, different color

• Differential pressure gauge, with voltage free contact

General Specifications

Compressed air inlet pressure: 1-16 barg / 15-232 psig Max. ambient air temperature: 66°C / 151 °F (35°C / 95 °F for V grade)

Available grades:

• P: pre-filter

• G: fine filter

• C: super fine filter

• V: activated carbon filter for oil vapor

• S: dust filter

• D: dust filter- high efficient

Pneumatech’s flanged filter range contains the same type of robust, high-efficient filter cartridges as the threaded range. The cartridges are contained in a welded steel housing which is pressure-rated up to 16 barg / 232 psig and provided with flanged connections at the compressed air inlet and outlet. The filter housings are completely cleaned, zinc phosphate and KTL coated at the inside and outside and externally painted afterwards. This guarantees a housing lifetime of at least 20 years. All flanged filters are standard equipped with a zero-loss electronic drain and differential pressure gauge with voltage-free contact connections. The special rotating system of the bottom cover makes filter cartridge replacement very straightforward.

Technical specifications for flanged filters FF 1-12

TF 1 - 11 - Threaded filters

Features & Benefits

Guaranteed air purity

• High-efficient glass fiber and foam media

No risks of:

• Cracked filter media

• Cylinder implosion

• Top cap leakages

• Oil re-entrainment

Significant energy savings

• Optimal filter media selection allows low pressure losses

Highest quality standards

• In-house research, development & production

• Each filter subjected to rigorous quality control

• Fully tested and qualified according to ISO standards

Robust design

• Stainless steel cores guarantee ultimate strength

• Protection paper to avoid damaging of glass fiber media

• Anti-corrosive coated filter housing

Easy service and installation

• Push-on filter cartridges elements

• Different grade, different color

• Differential pressure gauge on HE range (indicator for sizes 1 to 3)

General Specifications

Compressed air inlet pressure: 1-16 barg / 15-232 psig

Max. ambient air temperature: 66°C / 151 °F (35°C / 95 °F for V grade)

Available grades:

• P: pre-filter

• G: fine filter

• C: super fine filter

• V: activated carbon filter for oil vapor

• S: dust filter

• D: dust filter - high efficient

Options

Connection kit Potential

free conta

Wall mounting kit Differential

Pneumatech offers a comprehensive line-up of innovative filter solutions to meet your specific needs. Our state-of-the-art test facility allows to perform all tests according to ISO 8573 & ISO 12500 standards in-house. In this way we can optimize and validate our products to the maximum; and bring best-in-class filters to the market. From operations side, we distinct ourselves with our high level of automation and quality control in a triple certified manufacturing environment.

A filter is only as good as its weakest link. This explains our choices for two perforated stainless steel filter cores (strength), additional protection layers between filter media and core (no cracks), double O-rings for proper cartridge fixation (no leaks) and epoxy sealed end caps (guaranteed fixation). In this way, we can guarantee the highest air purity at lowest operational costs throughout the entire service life of the filter.

Technical specifications for threaded filters TF 1 - 11
