CompAir

Condensate treatment

The convincing concept for condensate discharge

The electronically level-controlled condensate drains from CompAir are the industrial standard for reliable cost-effective condensate drainage.

Benefits

• Fast installation and very easy maintenance
• Sensor control offering high reliability
• Discharge according to demand
• High quality aluminium housing

High efficiency compressed
air filtration & water separation

Technical Data - Compressed Air Condensate Separators - X Series

X-Series of water separators

The X-Series of water separators provide bulk condensed water and liquid oil removal and are used to protect coalescing filters against bulk liquid contamination.

X006 X024 X066 X210 X480 X600 X1080 X2880 X4320

Technical Data - Compressed Air Filter - CF Series

CF-Series of cast filters

The CF-Series of filters efficiently removes water and oil aerosols, atmospheric dirt and solid particles, rust, pipescale and micro-organisms.

CF0006 CF0012 CF0018 CF0036 CF0066 CF0096 CF0132 CF0258 CF0372 CF0600 CF0744 CF1116 CF1488 CF2232 CF3720 CF5208

FABRICATED HOUSING

CF-Series of flanged filters

For larger flowrate or higher pressure applications the flanged filters are available in the standard five filtration grades.

Filtration

A filter range to rely on

The reliability of compressed air filtration is paramount to the ongoing fight against problems caused through contamination entering the air system. The CompAir filter range has been constantly innovated and has become a leading technology, providing the exact balance between air quality, energy efficiency and low lifetime costs.

To meet the various requirements, CompAir filters are available in three different grades:

Type B: General Purpose Protection

Particle removal down to 1 micron, including water and oil aerosols.

Type C: High Efficiency Oil Removal Filtration & High Efficiency Dust Filtration

Particle removal down to 0.01 micron, including water and oil aerosols.

Type D: Oil Vapour & Odour Removal

·        X-Series of water separators

·        The X-Series of water separators provide bulk condensed water and liquid oil removal and are used to protect coalescing filters against bulk liquid contamination.
