Водонепроницаемый светодиодный драйвер WODE 120W 48V 2.5A AC DC с постоянным напряжением Ip67

Сохранить в закладки 60745449510:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики





Product Description


WODE 120W 48V 2.5A AC DC Constant Voltage Waterproof Ip67 Led Driver


♦ Features


1) High Efficiency And Good Price


2) Built-in EMI Filter


3) 100% Full Load Burn-in Test


4) Low Output Ripple And Noise
5) Protection:Over Load / Over Voltage / Short Circuit


6) Most items could provide adjustable +-10% for output voltage


7) Could meet the demand perfectly both for 220V and 110V input voltage


8) Could provide customized power supply for special output / special input / special protection etc.





*** Please note: We maybe modify the products according to different situation without informing.












































































































































MODEL



BG-120-5



BG-120-12



BG-120-24



BG-120-36



BG-120-48



OUTPUT



DC output voltage



5V



12V



24V



36V



48V



Rated output current



24A



10A



5A



3.33A



2.5A



Wave and noise



100mVp-p



100mVp-p



100mVp-p



100mVp-p



100mVp-p



Intet stability



±0.5%



±0.5%



±0.5%



±0.5%



±0.5%



Load stability



±1%



±1%



±0.5%



±0.5%



±0.5%



Efficiency



80%



81%



83%



83%



83%



INPUT



AC voltage range



AC85~265V wide range 47~63Hz



AC inrush current



Cold-start current 30A/250V



PROTECTION



Overload



Protection type : Constant current limiting, recovers automatically after fault condition is removed



Over voltage



121%~142% Rated output voltage



Short circuit



Protection type: shut off



ENVIRONMENT



Setup rise hold up time



100ms 60ms/230VAC at full load



Withstand voltage



Input and output internal:1.5KvAc,input and enclosure:1.5KvAc,Output and enclosure:0.5KvAc



Isolation resistance



Input and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ



Working temperature and humidity



-10~+50°C



Store temperature and humidity



-20~+85°C, 10~95%RH



OTHER



Overall dimension



189*49*34mm   24pcs/Carton ( common packing )



Weight



0.88KG



CERTIFICATE



CE EMC Authenticate



EN55022:2010 EN61000-3-2:2006+AL:2009 EN61000-3-3:2008



EN55024:2010 EN55015:2006+AL2007+2009 EN61547:2009



EMC CE LVD Authenticate



EN61347-1:2008T A1:2001 EN61347-2-13:2006



EN60950-1:2006+A11:2009+A1:2010+A12:2001



ROHS Authenticate



EPA3050B:1996 EN1122B:2001 EPA3052:1996 EPA3060A:1996



EPA7196A:1992 EPA3540C:1996 EPA8270D:2007 IEC62321:2008





















Company Information





Wode Electrical Co.,Ltd. was established in 2005 as a professional Power Supply manufacture.Our products cover the following series: Switching Power Supply, water proof IP67 Led driver ,AC/DC converter.These products are widely usde in the fields of LED strip,CCTV system,CNC machine,Outdoors power supply,PLC control system, Interruption accident etc.
