167 CFM General Purpose Coalescing Filter | Atlas Copco DD70+

167 CFM Activated Carbon Filter | Atlas Copco QD70+

QD(+) oil vapor filters

Our high-performance oil vapor removal filter removes oil vapor and odors from compressed air.

Our QD(+) is engineered to cost-effectively provide the best quality air and meet today’s increasing quality demands.

ir purity

The QD’s highly efficient activated carbon layers with high absorption capacity guarantee maximum oil vapor removal

QD ensures optimal oil vapor filtration

Our QD(+) activated carbon filter efficiently reduces oil vapour and odors in your compressed air stream to protect your investment, equipment and processes. The activated carbon layers will, by the use of adsorption, reduce the residual oil content to less than 0.003 mg/m³. The pressure drop remains minimal throughout the lifetime of the filter.

Performance

QDT activated carbon tower

The high-efficiency activated carbon tower removes oil vapor and odors from your compressed air set-up.

Our UD+ QDT filter combination is certified for meeting the requirements of air purity class 1 for total oil, according to ISO 8573-1:2010.

Maximum oil vapor removal

The QDT’s superb activated carbon material with high absorption capacity guarantees air purity over its entire lifecycle, with service intervals of one year or 4,000 operating hours, whichever comes first.

Easy installation

Either with the self-supporting floor mounting or the optional wall mounting kit, installation of our QDT is easy and straightforward.

Peace of mind

Our QDT provides peace of mind with its robust head and housing design, along with its spring-loaded activated carbon bags to avoid channelling.

Small footprint

Compared to traditional vessel designs the QDT is extremely compact.

QDT for optimal oil vapor filtration

In pharmaceutical, food & beverage, electronic and other industries where air purity is critical, you need to remove residual oil vapors and odors from your compressed air supply. The activated carbon layers in our QDT will, by the use of absorption, reduce the residual oil content to lower than 0.003 mg/m³. Pressure drop remains minimal throughout the filter’s lifetime.

QDT SERIES

Activated carbon towers for optimal

oil vapor filtration

The high efficiency activated carbon tower is capable of removing hydrocarbons, odors and oil vapor from compressed air. The activated carbon layers will, by the use of adsorption, reduce the residual oil content to lower than 0.003 mg/m3.The pressure drop is low and stays minimal during the filter’s lifetime.

Performance

Sizing & dimensions

DDp(+) and PDp(+) dry dust filters

Our high-quality dry dust filters remove dry dust, particulates and micro-organisms from compressed air.

Our DDp(+) and PDp(+) are engineered to cost-effectively provide the best quality air and meet today’s increasing quality demands.

DDp and PDp ensures optimal dry dust filtration

Our DDp(+) and PDp(+) dry dust filters efficiently prevent dust, particulates and micro-organisms arising from corrosion, dirt and adsorption material from entering your compressed air stream.

DDp(+)/PDp(+) SERIES

Optimal dry dust filtration

DDp(+) and PDp(+) filters efficiently prevent dust, particulates and micro-organisms arising from corrosion, dirt and adsorption material from entering your compressed air stream. These innovative filtration solutions are engineered to cost-effectively provide the best air purity and meet today’s increasing quality demands.

Performance

SIZE AND DIMENSION

DD(+)/PD(+) SERIES

High performance oil coalescing filters

DD(+) and PD(+) filters efficiently reduce oil aerosol, wet dust and water drops in your compressed air stream. These could come from the lubrication of the compressor element, the intake air, and the compressor installation itself. These innovative filtration solutions are engineered to cost-effectively provide the best air purity and meet today’s increasing quality demands.

DD(+) and PD(+) oil coalescing filters

Our high-performance oil-coalescing filters remove oil aerosol, wet dust and water drops from compressed air.

Our DD(+) and PD(+) are engineered to cost effectively provide the best air purity and meet today’s increasing quality demands.

DD and PD ensures optimal oil coalescing filtration

Our DD(+) and PD(+) oil coalescing filters efficiently reduce oil aerosol, wet dust and water drops in your compressed air stream to protect your investment, equipment and processes. These impurities could come from the lubrication of the compressor element, the intake air, and the compressor installation itself.

PERFORMANCE:

DIZE DIMENSION:

UD+ SERIES

Two-in-one oil coalescing filters with supreme energy savings

UD+ filters efficiently reduce oil aerosol, wet dust and water drops in your compressed air stream to protect your investment, equipment and processes. The UD+ combines two filtration steps (DD+ and PD+) into one, a unique technology to meet the high-quality requirements of diverse applications and provide ultimate energy savings.

UD+ oil coalescing filters

Reduce energy costs by 40% with the UD+ two-in-one oil coalescing filtration solution. Best-in-class air purity. Protect your investment, equipment and processes.

Next generation of filtration solutions

Atlas Copco has launched the UD+ coalescing filters, which combine two filtration processes in one product. The UD+ is unique in the market and offers energy savings, efficiency gains and reliably clean compressed air.

40% energy savings

A 40% lower pressure drop than the conventional line filter combination results in 40% higher energy efficiency thanks to our unique Nautilus filter technology.

Small footprint

The two-in-one filtration concept reduces installation space and complexity, making these filters particularly suitable for applications where space is at a premium.

Save money

Install the UD+ to enjoy significant cost savings compared to conventional filters.

Pure air

Air purity is equal to that obtained using two conventional filters in line, thanks to the design of UD+ filters and the media used.

No risk of cracks in filter media

Nautilus filter technology runs no risk of cracks in the filter media because the filter media are wrapped around the filter.

Two-in-one filtration with supreme energy savings

Our UD+ oil coalescing filters efficiently reduce oil aerosol, wet dust and water drops in your compressed air stream to protect your investment, equipment and processes. The UD+, combines two filtration steps (DD+ and PD+) into one, a unique technology to meet the high-quality requirements of diverse applications and provide ultimate energy savings.

 PERFORMANCE:

SIZE AND SPECIFICATION UD+:

SFA silicone-free filters

Our SFA filters provide exceptional air purity for applications where silicone-free air is required, such as painting and automotive. Protect your end-products.

Silicone-free removal of oil aerosol, dust and oil vapor.

Guaranteed silicone-free

We produce our SFA filter housings and elements in a clean room environment and clean and test them according to certified procedures.

Maximum contaminant removal

Our SFA filter ensures maximum removal of dry and wet dust, particulates, oil aerosol and water droplets through its high-efficiency glass fiber and fleece media.

Energy savings

The design and media used for our compressed air filters minimize reduction in pressure.

High performance

High-quality materials such as stainless steel cores, double O-rings, epoxy sealed caps and anti-corrosive coated filter housings are selected to ensure high performance and reliability.

Easy maintenance

Push-on elements and external ribs on the threaded housing make filter maintenance easier.

SFA ensures superb air purity

Our high-quality silicone-free SFA filters safeguard your instruments and end products by efficiently preventing dry and wet dust, particulates, oil aerosol, oil vapour and water drops from entering your compressed air system. The SFA is certified by the Fraunhofer Institute as guaranteed silicone-free.

Why choose SFA silicone-free filters?

Although our standard compressed air filters thoroughly clean air, they still have potential to release silicone into the air stream from lubricants, components and processes used during manufacturing. That’s why it is crucial to install SFA silicone-free filters to prevent major problems from occurring such as paint defects like craters and blisters, or even poor paint adhesion.

 Examples of typical installations

A SOLUTION FOR EVERY APPLICATION
At different points of use, different compressed air purities might be needed, depending on the application.
The various air purity classes are provided in the table below, which clearly shows the various Atlas Copco filters and dryers that meet all the different classes.

SFA silicone-free filters

Our SFA filters provide exceptional air purity for applications where silicone-free air is required, such as painting and automotive. Protect your end-products.

Silicone-free removal of oil aerosol, dust and oil vapor.

Guaranteed silicone-free

We produce our SFA filter housings and elements in a clean room environment and clean and test them according to certified procedures.

Maximum contaminant removal

Our SFA filter ensures maximum removal of dry and wet dust, particulates, oil aerosol and water droplets through its high-efficiency glass fiber and fleece media.

Energy savings

The design and media used for our compressed air filters minimize reduction in pressure.

High performance

High-quality materials such as stainless steel cores, double O-rings, epoxy sealed caps and anti-corrosive coated filter housings are selected to ensure high performance and reliability.

Easy maintenance

Push-on elements and external ribs on the threaded housing make filter maintenance easier.

SFA ensures superb air purity

Our high-quality silicone-free SFA filters safeguard your instruments and end products by efficiently preventing dry and wet dust, particulates, oil aerosol, oil vapour and water drops from entering your compressed air system. The SFA is certified by the Fraunhofer Institute as guaranteed silicone-free.

Why choose SFA silicone-free filters?

Although our standard compressed air filters thoroughly clean air, they still have potential to release silicone into the air stream from lubricants, components and processes used during manufacturing. That’s why it is crucial to install SFA silicone-free filters to prevent major problems from occurring such as paint defects like craters and blisters, or even poor paint adhesion.

THE ATLAS COPCO SOLUTION

Compressed air can be contaminated by dirt, water and oil, which can be further divided as follows:

• DIRT: micro-organisms, dust, solid particles, rust particles.

• WATER: water vapor, condensed liquid water, water aerosols, acidic condensates.

• OIL: liquid oil, oil aerosol, hydrocarbon vapor.

Atlas Copco offers a wide selection of filtration solutions and application knowledge. Different product types and grades are available to meet your every demand. Only genuine spare cartridges guarantee the Atlas Copco filter performance.

Atlas Copco

Compressed air filters and filtration solutions

A wide selection of filtration solutions for compressed air with different filter types and grades. Supported by our expert application knowledge.

In-house development and testing

Our dedicated filtration team is responsible for in-house development of cutting-edge filtration solutions. This results in expert know-how of filtration mechanisms, state-of-the-art test facilities and breakthrough innovations.

Rigorous quality control

To ensure highest standard, the entire filter range is produced in-house, on the most advanced production lines, using the most stringent methods in the industry.

Certified performance

All tests are performed in-house according to ISO 8573 and ISO 12500 standard, as well as in external labs, and are independently validated by TÜV.

Air filters

A wide selection of filtration solutions for compressed air with different filter types and grades. Supported by our expert application knowledge.

Importance of filter

Get clean compressed air by using the right compressed air filters. Protect your pneumatic equipment.

Compressed air filters protect your equipment from dust, dirt, oil and water. Dust will wear down your equipment (like the air motor in grinders, pneumatic actuators and it can make pneumatic control valves get stuck.Especially when the dirt and dust is combined with oil (which is often the case with compressors), a sticky mess can form inside valves, motors and other compressed air equipment.

To protect your equipment, you need to install some compressed air filters.

Which ones? Find out below…

There are many different kinds of filters, and I have often seen people using the wrong one.

I have seen many ‘compressed air filter mistakes’ for that matter, like: wrong filters installed, too small filters installed, filters installed in the wrong place.

People also tend to forget about their filters… while the compressor gets its service every year, people seem to think that their filters will last a lifetime!

That’s not true of course… and it will cost you money!

Filter build-up

Look at the picture below what a typical filter looks like. The workings are quite simple: air enters on one side and goes through the filter element, where all dust, water or oil is collected. The clean air then leaves the filter housing on the other side.

Take Atlas copco filter as example,

Filter types

So you need a compressed air filter, but are overwhelmed by all the different types, sizes and specifications. Don’t worry! Let me help you..There are:

Particulate filters

Particulate compressed air filters are used to remove dust and particles from the air.

Coalescing filters

Coalescing filters are used to capture oil and/or moisture that is suspended in the compressed air in very tiny droplets.

Activated carbon filters

Activated carbon filters will remove odors and vapors. They are used in factories where food is produced or for breathing-air for example.

Filter elements

As you can see above, the compressed air filter usually is made up of two main parts: the housing and the filter element.

The filter element itself is the part that is doing the job: filtering your compressed air.

In some cases, the filter housing is doing an important job too: it’s often used to separate dust or water/oil droplets by cyclone action. What does it mean? The housing is designed in such a way that the compressed air moves around in it like in a tornado. All the solid particles and droplets will get smashed into the walls of the housing, while the rest of the air moves to the filter element.

You can buy the filter elements separately from the housing, so you can change them for new ones every year or so.
