Ультразвуковой измеритель уровня низкого энергопотребления RS232 RS485 выходной датчик топлива
- Категория: >>>
- Поставщик: Shenzhen Dianyingpu Technology Co. Ltd.
Сохранить в закладки 60749798901:
Описание и отзывы
Характеристики
Product Description
Specification
| Model | L03 | |
| Product Name | Liquid level Ultrasonic sensor | |
| Highlight | Non contacted measuring, no need change the shape of container. Metal case & waterproof, suitable for harsh environment Wide voltage power input supported. Small size, easy to install. Strong anti-interference, anti-static abilities Real-time trace liquid level status, empty container no need restart. Multiple output methods, RS232/RS485. Long measurement range, high accuracy to 1mm. High frequency ultrasonic, high solid penetration, suitable for containers made of various materials such as metal and plastic UART automatic output, quickly response, not occupy hardware resources Low power consumption, standby current lower to 1uA. Comes with temperature compensation. | |
| Operating Voltage | 12-48 v | |
| Average Voltage | <25 mA | |
| Blind Area Distance | 5 cm | |
| Measuring Range | 5-200 cm | |
| Available Container Thickness | 0.6-5 mm | |
| Accuracy | <8 mm | |
| Resolution | <1 mm | |
| Output Method | RS232/RS485 | |
| Measuring Angle | 2-4° |
Application
 | ||
| Liquid Level Measurement in Small Bottles | Loop control | Diameter Sensing and Strip Speed Control |
 | ||
| Contour Recognition | Quality Control | Vehicle Sensing and Positioning |
 | ||
| Wire or Rope Breakage Monitoring | Stack height sensing | Bottle Counting |
 | ||
| Breakage Sensing | People Sensing, Human body Height measurement | Liquid Level Measurement in Large Vessels(Tanks, Silos) |
 | ||
| Flat Object sensing or detection | Anti-Collision, Proximity Alarm | Height Sensing |
Certificates
FAQ
1. Are you a manufacturer or trading company?
DYP is a manufacturer, our factory approved by ISO9001:2008, ISO14001:2004 standard.
2. Does your products can be ODM or OEM?
Yes, we provide ODM/OEM services, we can customize the product according to your requirement, after estimated by our R&D team, We can build the product you need on the basis of existing products, or build a brand new product.
3. What's warranty of your product?
We provide 1 year warranty, any defective items, please send back to us, we will repair/replace for you.
4. What is the terms of payment?
for the sample order, we suggest place order on alibaba directly. for the large order, we accept TT or LC.
5. Do you provide technical support?
Yes, we have our own R&D department, we can provide you technical support at any time. you can call us or write email to us.
6. How to choose the right ultrasonic sensor?
First of all, clarify the installation conditions:
a. Medium to be measured;
b. Installation location;
c. Measurement range;
d. Measurement accuracy;
e. Sensor resolution;
f. potential interference;
g. Whether vessels has pressure.
Select the corresponding series of products according to the medium, and then select the product suitable for the conditions according to the Range, Accuracy, Angle etc parameters. If there is no suitable one, we also provide OEM/ODM services, please contact us.
Company profile
We were established in 2008, located in shenzhen of china with a convenient transportation access, SHENZHEN DIANYINGPU TECHNOLOGY CO LTD is a professional manufacturer and exporter, which is dedicated to the design, research, development and production of Ultrasonic Sensor.
All of our products comply with international quality standards and are greatly appreciated in a variety of markets throughout the world. Covering an area of 30,000 square meters, we no have more over 180 skilled employees, boast an annual sales figure that exceeds USD 63,000,000 and currently export 72% of our production worldwide.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction, Besides, we have approved ISO9001:2008, ISO14001:2004 quality standards. Due to our high quality products and outstanding customer service, we have gained a global sales network reaching Europe, South America, North America, Australia, Mid-East and Southeast Asia.
If you are interest in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to establish a successful business relationship with new clients around the world. |
Contact us
Shenzhen Dianyingpu Technology Co Ltd.
Factory address: 7th floor, Block A, Dahong
High-Tech Industrial Zone, Shajing street,
Baoan district, Shenzhen 518000,
China.
Tel: +86 755 8524 5641
