1.54 Inch IPS TFT LCD Module 320x320 Square LCD Display



Product Specification:

Item	1.54 Inch TFT LCD Module
LCD Type	TFT Transmissive, Normal Black
Part Number	TST1540HVBS-01
Resolution	320xRGBx320
Outline (mm)	31.82x33.87x1.80
Active Area (mm)	27.74x27.74
Viewing Direction	ALL
Contrast Ratio	900
Luminance	280±30
Touch Panel	Without
Drive IC	ST7796S
Interface	MIPI
Backlight	3-LED
Operating Temperature (℃)	-20 to 70
Storage Temperature (℃)	-30 to 80
Pixel Arrangement	RGB Vertical Stripe
Surface Treatment	Anti-Glare
Weight (g)	TBD
Operating Voltage	3.3V
Color Depth	262K/16.7M
Driver Element	a-Si TFT Active Matrix



Detailed Images:







Company Profile:

SHENZHEN TEAM SOURCE DISPLAY TECHNOLOGY CO, LTD. (Brand:TSD ) was established in 2004. Head Office located in Shenzhen, China.



TSD's business scope covers LCD / LCM Module development, single-chip production and material
processing. With more than 10 years' experience, we have developed thousands of LCD and LCM products for
industrial, home appliances, consumer electronics, medical equipments and other applications.



TSD worked on a full range of LCD products and LCD solutions & development, offering customer unique, innovative, cost-effective yet market leading modules, to support a wide range of applications and industries.TSD's strong, professional and experienced R&D engineers will provide customers with new product developments, both hardware and software designs in a quick and effective way.



We follow a way of people-oriented, quality & customer first in all of our dealings. That's why we create a good working environment both for our staff and for the product manufacturing process. To get more benefits for dealing with us, contact us now for any of your LCD/LCM/LCD solution projects and requirements.



Our Team:

Certificates:

Professional Processing:

Applications of our products:



Customers:

Packing & Delivery:

FAQ:

Q: What’s precise price of the product?

A: Please send us your inquiry of the product, base on your requirement & quantity, we will quote the exact price within 24 hours.



Q: What are the payment terms?

A: We usually accecpt T/T, Paypal, other terms to be negotiated.



Q: How to customize the product?

A: Please tell us your requirement through inquiry. Customized procedures goes like this: Project scope clarification → Fill TSD Requirements form → Engineering analysis → Cost Evaluation → Customer confirmation → Pre-drawing or specification → Customer confirmation → Sampling → Customer approval → Mass Production



Q: Can’t seem to find the right product.

A: Send us your requirements, we will offer you the best solution, first by recommending our standard products, if it cannot help, then we can do the neccesary adjustment & customization.



Q: Do you accept sample order or small quantity order?

A: Yes, you can place sample orders for product testing, and small quantity order (not less than MOQ) as pilot production.



Q: What’s the lead time?

A: Usually 3-5 days for sample orders, and 2-4 weeks for massive production (based on the quantity and product).
