ZX7 300 Электрический мини портативный инвертор постоянного тока mma сварочный аппарат дуговой
- Категория: >>>
- Поставщик: Nanning Chuanjun Welding Hardware Co. Ltd.Nanning Ltd.
Сохранить в закладки 60775915517:
Описание и отзывы
Характеристики
ZX7 300 Electric Mini Portable DC Inverter mma welder Arc Welding Machine
Product Description
Function and featurres of inverter igbt ac dc mma welder ZX7 300
1. Three-phase power supply, the input voltage of 320V~450V can work normally, the requirements on the power grid are low, and the adaptability is strong;
2. Key components imported, brand-name power switch, circuit board three anti-paint protection;
3. For the arc-ignition characteristics of the electrode for manual arc welding, the output is designed to reduce the inclination characteristics;
4. Easy to start arc, easy to control arc, mature technology, stable and reliable;
5. High duty cycle, long welding 4.0mm welding rod;
6. DC output, adjustable thrust, and current digital display are intuitive;
7. The acid-base electrode is common and the welding process is stable;
PRODUCT PARAMETERS
Model Number | ZX7 300 |
Rated Input Voltage(V) | Three Phase 380V±15% |
Input Frequency (HZ) | 50/60 |
Rated Input Power(KVA) | 12 |
Current Voltage Regulation Range (A/V) | 30-240 |
40℃60% Temporary Load Rate Output(,A/V) | 210 |
40℃,100% Temporary Load RateOutput (A/V) | 165 |
Thrust Control | 0~100 |
No-load Voltage(V) | 77 |
No-load Loss (W) | 80 |
Efficiency (%) | 85 |
Power Factor | 0.93 |
Class of Insulation | F |
Protection Class | IP21S |
Weight(KG) | 17.5 |
Size(mm) | 505*203*375 |
Product Overviews
Company Information
Nanning ChuanJun Welding Hardware Co., Ltd. , founded in 2004, focus on welding equipment and accessory for more than 10 years. Our products are MMA, TIG welder, MAG/MIG welding machine, SAW welding machines, cutting machine, welding accessories, and welding materials.
Workshop
Quality Control
Warehouse
FAQ
1.Q:Are you a factory or trading company?
A, Yes we are the factory and have 5 production lines for us.
2.Q:Does the machine have CE certificate?
A:Yes, others certifications also can be sent
3.Q:What's the shipping method?
A: International express and sea transportation,Depend on customer.
4.Q:Can I use my own forwarder to transport the products for me?
A:Yes, if you have your own forwarder in China, you can let your forwarder ship the products for you.
5.Q:What's the Payment method?
A:T/T, 30% deposit before production, the balance before delivery.(only big order)
We sugguest you transfer the full price at one time. Cause there is bank process fee, it would be a lot of money if you make twice transfer.
6.Q: What is our payment term?
A:We can accept the payment by Credit card and T/T and Trade assueance .
7: Can you send me the video to show how the machine works?
A: Certainly, we have made video of every machine.
Q: How can I know your machine works well?
A: Before delivery, we shall test the machine working condition for you.
8.Q:How to Place an order?
A:Please kinldy send us your order by email,we will confirm the PI with you .we wish to know the below:your details address,phone/fax number,destination,transportation way ;
Product informaiton:item number,size,quantity,logo,etc
