Product Description

CNC Drilling Machine Milling Machine

CNC Drilling and Marking line for angle steel

Product Application

PD series CNC plate drilling machine mainly do the drilling process of the junction plate and base anchor which used widely in steel structure, iron tower, bridge, and machining industries etc., and also used widely for flange drilling process.

Main Features

1. This processing line is composed of transverse conveyor, overturn conveyor, infeed conveyor, CNC infeed carriage, two sets of drilling units, one set of marking unit, automatic unload conveyor and corresponding hydraulic station, electric cooling system.
2. Adopt CNC technology, servo motor in feeding, with high efficiency, stable work piece precision.

3. There is one set of drilling unit on each side. Every drilling unit can be installed with three drills of different dimensions. The drilling unit can realize the CNC movement holistically for change of drilling stadia, therefore to ensure the accuracy of holes.
4. Rotation speeds of all spindles are stepless adjustment realized by transducer, and feeding speeds are also stepless adjustment realized by speed regulating valves. Transform of the rapid feeding, work feeding, and rapid withdrawing of spindles all are finished automatically.
5. One marking unit in the drilling line. Marking stadia can be preset conveniently. Marking, clamping of the workpiece and infeed of the drilling are driven by the hydraulic system. Main components are imported. Circulate cooling system is applied so as to prolong the life of drills.
6. The control system consists of the host computer, servo motor, PLC, external monitoring switch, etc. Just input the dimension of the workpiece, the processing program will be generated automatically. Besides, the program can be saved, selected, displayed and communicated as per the workpiece No.
7. The machining line installs supporting & pressing device to meet the requirements of processing angles with bigger bending.

Work Piece

Specifications

SPECIFICATIONS
Model	HADM2532	HADM3635
Angle Size(mm)	14014010-25025032	140140810-360360*35
Max. Length of Raw Material(m)	14	14
Marking Force	1030KN
Morse Taper of Main Spindle	BT40
Max.Drilling Diameter	26mm
Marking Unit Type	close Type
Back Marking (mm)	50-220stepless	50-330stepless
Qty. of character Group	1
Character Qty.	15
Character Size	141019mm
Max. Moving Speed(m/min.)	40
Overall Dimension(LWH)(M)	About 307.53	About 33.38.93
Net Weight(kg)	About 30000	About 34000

Detailed Images

Machine Parts

Name: Lubrication System

Brand:Herg

Original: China

Domestic famous brand name of lubrication system, the lubrication is automatically

Electrical Configuration

Name: Electrical Parts
Brand: World Famous Brand

Original: Japan, China Tawin etc.
We adopts world famous brand name key electrical parts to assure the high quality and stability of the machine, long-life usage.
