Product Description






MJ375-D Electric Type Upgrading:



I. The clamping device is changed from manual screw rod clamping to pneumatic automatic clamping, which resolves the defect that manual clamping causes log looseness and the larger sheet material is reserved when the last piece is cut, and enhances the reliability & safety related to clamping of wood to be processed. The whole cutting process can be completed only by clamping once.



II. Have a rack adjustment device, convenient for adjustment of the rack guide rail, with flexible removal & installation, which enormously reduces the requirements of user ground foundation. Upgrading cannot only improve production efficiency, but also optimize product structure, so that the user operation is more convenient and practical to achieve the win-win purpose.



Click to view the video




Technical parameters:



Specification’s Items

MJ375-D

Max. wood diameter

620mm

Saw wheel diameter

473mm

Max. cutting height

620mm

Max. cutting width

620mm

Blade Speed: Standard for Common Wood

780 r/min

Max. cutting length

5200mm

Total output power of motor

10.1kw

Main cutting motor power

9kw(380V,50Hz,3phase)

Lifting motor power

0.55 kw

Forward and reverse motor power

0.55 kw

Cutting forward speed

0-15m/min

Cutting reverse speed

17m/mim

Blade dimensions

4005×34×1.05mm

Track length (Standard)

6000mm

Overall dimensions (LXWXH)

7200×2000×2000mm

Packing size(LXWXH)

2200×950×2100mm

Total weight (Standard)

800kg



Performance and Features:

(1)Automatic operate, simple , safe and pro-environment;



(2)The wood sawing process electric control, electric lifting and automatic clamping



(3)Automatic control the timber thickness, high-precision.



(4)High cutting efficiency, smooth; high flatness of the cutting plate;



(5)Apply to sawing process for the lumber plant scale production or forest area.



(6)There’s no need the professional sawyers, the ordinary workers can operate the machine expertly.








More products

more-product-













1. All the prices are FOB Shanghai. Include packing charge;

2. Payment Terms:  T/T 30% as deposit after signing contract, and 70% before shipment;

3. Delivery Time:  Within 30 days after receiving the deposit.
