Product Description
Seismic resistance neoprene isolators for bridge
Seismic resistance neoprene isolators for bridge are made of multilayer Neoprene/EPDM/natural rubber with or without sheet steel after inlay, conglutinate, vulcanization. It has enough vertical stiffness to support vertical load, and it could deliver the pressure of superstructure to abutment.

Applications

Seismic resistance neoprene isolators for bridge can be used for steel structures, pre-cast concrete structures, standard concrete slabs, and anywhere needs vibratuin isolation. This type of bearings provide an excellent economic solution for applications where structure movements, longitudinal, transverse and rotational are small, provide vibration isolation and are generally simple to install.

Features.

Shock absorption neoprene hard rubber pads
Technical performance.
\t
Characteristics
\t
Requirements
\t
Material
\t
CR
\t
NR
\t
EPDM
\t
Hardness
\t
60±5
\t
60±5
\t
60±5
\t
Tensile strength / MPa
\t
17.0
\t
18.0
\t
15.0
\t
Elongation at break / %
\t
400
\t
450
\t
350
\t
Brittle temperature ℃
\t
-40
\t
-50
\t
-60
\t
Compression set %
\t
15
\t
30
\t
25
\t
Tensile bond strength between rubber & steel plate MPa (kgf/cm2)
\t
≥3.0
\t
≥3.0
\t
≥3.0
\t
Constant compression deformation%(70℃×22h)
\t
≤25
\t
≤25
\t
≤25
\t


Air aging
\t
Testing Conditions ℃×h
\t
100×72
\t
70×168
\t
100×70
\t
variation in hardness (shore A)
\t
0-10
\t
0-10
\t
0-10
\t
Tensile Strength change rate (Mpa)
\t
≥-10
\t
≥-15
\t
≥-10
\t
Elongation at break change rate %
\t
≥-30
\t
≥-20
\t
≥-20
\t
Ozone Aging IPPM30℃×100h
\t
No crack
\t
Bending fatigue
\t
No crack after bending 6×10 times
\t
Item
\t
Index
\t
Ultimate compression strength Rd /MPa
\t
≥60
\t
Compression modulus of elasticity E1/ MPa
\t
E±E×20%E
\t
Shear modulus of elasticity G1 / MPa
\t
G±G×15%G
\t
Allows maximum shear deformation tg α
\t
≤0.7
\t
shear deformation produced by fast loading tg α
\t
≤0.25
\t

Anti-sliding friction coefficient
\t
Against steel
\t
0.2
\t
Against concrete
\t
0.3

Contact us for details.

Seismic resistance neoprene isolators for bridge

Products Show

Contact us for details.

Seismic resistance neoprene isolators for bridge

Packing & Delivery

Packing Details: Platic film and pallets.
Delivery Details: 10-30 days after deposite.

Our Company

Hongrui Boya (belongs to Shuanglin Group) professionally supplys Road, bridge and building support, expansion joint, waterproof materials.
It has one factory, three companies for domestic and foreign markets. 50 workers, 8 enginnerings, and over 20years experience of manufacture.
Main products are Bridge bearings, bridge expansion joint, concrete waterstop products, rubber air bag, polysulfide sealant etc.
ISO certification, CE standard, AASHTO, and SGS test, with a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in infraconstruction and other industries.

Contact us for details.

Shock absorption neoprene hard rubber pads

Our Service
Related Products

Bridge Rubber Pot Bearing

Spherical PTFE Bridge Bearing

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 3-5 days if the goods are in stock. or it is 7-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=3000USD, 100% in advance. Payment>=3000USD, 30% T/T in advance ,balance before shippment.
