Экономичный токарный станок для металла с двигателем LC510 * 1500

PRODUCT FEATURES

*THE SURFACE OF THE BEDWAYS IS SUPERSONIC FREQUENCY HARDENED.
*GEARS PRECISELY GROUND TO REDUCE NOISE.
*SPINDLE SYSTEM IS OF HIGH RIGIDITY AND PRECISION.
*RAPID FEED STRUCTRUE IS AVAILABLE ON APRON.
*INTEGRAL CASTING BASE CAN BE OPTIONAL.

TECHNICAL PARAMETERS

SPECIFICATION

LC510/1000MM

LC510/1500MM

LC510/2000MM

CAPACITY

Max.swing over bed

510mm

Max.swing over cross slide

330mm

Max.swing over gap

660mm

Effective length of gap

200mm

Center Distance

1000mm

1500mm

2000mm

Bed Width

360mm

HEADSTOCK

Spindle hole

82mm

Spindle nose

ISO-C8

Spindle taper

MT8

Spindle speed(Number)

(9steps)40-1300rpm

FEEDS AND THREADS

Max.travel of top slide

95mm

Max.travel of cross slide

250mm

Max.size of toolshank

20*20mm²

Longitudinal feeds range

0.0832-4.66mm/r

Cross feeds range

0.048-2.69mm/r

Metric threads range

19kinds 0.25-14mm

Inch threads range

49kinds 2-40inch

Moudle threads range

11kinds 0.5-3.5mπ

TAILSTOCK

Dia.of tailstock sleeve

65mm

Taper of tailstock sleeve

MT4

Max.travel of tailstock

140mm

MOTOR

Main drive motor

5.5KW

Coolant pump motor

90W

PACKING

L*W*H

242*112*175cm

292*112*175cm

342*112*175cm

WEIGHT

N.W/G.W

1600/1800kgs

1800/2050kgs

2000/2300kgs

ACCESSORIES

STANDARD ACCESSORIES

PART:INSTALL ON THE LATHE

3-jaw chuck(Φ250mm)

Steady rest & follow rest

Longitudinal touch stop

Work lamp

Coolant system

Full-length splash guard

Foot brake and brake ribbon

PART:INSIDE THE PACKAGE WITH THE LATHE

4-jaw chuck(Φ320mm)

Change gears

Dead centre and centre sleeve

Face plate

Oil gun

Paddings

One whole set spanner and tool box

Operation manual

OPTIONAL  ACCESSORIES

Live centre(MT4)

2axis Digital readouts(SINO)

3axis Digital readouts(SINO)

Rapid travel(for 1000&1500mm length is optional; for 2000mm length is standard)

CE-conformity(Chuck guard,Toolpost guard and leadscrew guard)

USA type Quick change tool post

Europe or Italy type Quick change tool post

Drive plate

Thread-cutting dial

Magnetoelectrical brake

Drill chuck set

Taper cutting function

Cutting tool holders set(7pcs or 9pcs)
