KY330 Precision metal manual lathe engine

Сохранить в закладки 60786356457:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики


Product Description
\t
Specification
\t
Model No.
\t
KY330
\t
Max. Swing over bed
\t
330mm
\t
Distance between centers
\t
600mm/800 mm
\t
Max. Swing over cross slide
\t
210mm
\t
Spindle Bore
\t
38mm
\t
Taper of spindle bore
\t
MT.5
\t
Width of bed
\t
160mm
\t
Range of metric thread
\t
17/0.5∼4 mm
\t
Range of Inch thread
\t
20/40-9 TPI
\t
Range of longitudinalfeed
\t
0.175∼1.396mm/r
\t
Range of crosslfeed
\t
0.037∼0.296mm/r
\t
Top slide travel
\t
100mm
\t
Cross slide travel
\t
160mm
\t
Max. travel of tailstock sleeve
\t
70mm
\t
Taper of Tailstock sleeve
\t
MT.3
\t
Step of Spindle speeds
\t
12
\t
Range of Spindle speeds
\t
60∼1650mm/r
\t
Motor
\t
1100w/220v/ 50HZ
(or110v/60HZ)
\t
Net weight
\t
250kg
\t
packing size
\t
1550x770x700mm
\t
Standard Accessories
\t
3-Jaw chuck
\t
1set
\t
Chip tray & splash guard
\t
1set
\t
Safety chuck cover
\t
1set
\t
Dead centers
\t
1set
\t
Change gears
\t
1set
\t
Oil gun
\t
1pc
\t
Allen wrench
\t
1set
\t
Optional Accessories
\t
4-Jaw chuck
\t
1set
\t
Steady rest
\t
1pc
\t
Follow rest
\t
1pc
\t
Face plate
\t
1pc
\t
Rolling center
\t
1pc
\t
Steel Cutter(6pcs)
\t
1set
\t
Stand
\t
1pc
\t
Working lamp
\t
1pc
\t
Leadscrew cover
\t
1set
\t
Coolant system
\t
1set
\t
Foot brake system
\t
1set
\t
Quick change tool post
\t
1set
\t
Digital Readout
\t
1set

Main Features

--Widely useful,heary duty bench lathe.

--V-way bed is hardened and precision ground.

--Spindle is supported by high quality tapered roller bearing,

--Hardened,precision ground gears in headstock,

--Gearbox has large feed and threading functions.

--Carriage mounted spindle control lever.

--Adjustable gibs for slideways.

--Automatic feed and threading are fully inter locked.

--Tailstock may be offset for turning tapers.

--Equipped with emergency stop button.

Packing & Delivery
Warehouse to film
Related Products





                     KY400-1000







       KY1230A-2/KY1236A-2

Our company

 Since establishing, after years of effort, we, which is Kaiyun Machinery have grown into a professional supplier of Metalworking and woodworking machinery in Chain, with more than 50 domestic qualified factories as our long-term and OEM partners. Outstanding technical engineers & strict inspector ensure us turn out high quality products because they all know this is the absolutely vital that the quality is the basic of products. Our all products are exported to the worldwide markets, especially in America and Europe market.

Our service

You can enjoy the best after service when you purchase our any product. Our technician take serious to the every quality information feedback of our products each time, and would reply it as soon as possible. We will keep trying our best to guarantee your satisfaction, and to assure the product we send to you will meet the high quality and durable standards. If you are interested in our products or have special requirements, pls feel free to contact us without delay. Then we, Sale Dept will give you a satisfying reply within 24 hours!
