LT101 solar led aviation light

Main functions and features

• Based on LED technology,aviation special for red.


• Base material is aluminum alloy, PC lamp housing, UV resistant, with bird spike.


• Built-in photocell can switch ON/OFF the light at dawn and dusk.


• With falling prevention device.


• Buit-in Ni-MH battery, easy for replacement.


• NO RF - radiation, EMC compliant.


• Anti-vibration, corrosion resistance.


• Working stable, low maintenance costs.

Installation and Operation

• Mount the solar light in the most suitable place such as under direct sunlight, to ensure its continuous operation.


• Screw the lamp on the G3/4” threaded pipe, which should be fixed on a smooth surface with enough mechanical strength(see mounting drawing).


• When first operation, if the solar does not light up in dark places, please put the light under direct sunlight for approx. 12hrs.


• Please keep the light in a very dry and low temperature place, such as places with low humidity if do not use the light for a long time. Put the light under direct sunlight for three days every 40 days, to ensure the battery capacity.


• Built in NiMH battery, after being used 450 times(15 months), the battery capacity is approx. 80% of previous capacities, at this moment, please replace the battery in time.

Installation Dimension(Unit:mm)

Installation Instruction

Notice

• The part of material of products is PC( like lamp cover and lamp shell ), so it cannot direct or indirect touch the organic solvent, such as industrial alcohol, banana oil, isopropyl alcohol, carbon tetrachloride, cyclohexanone and so on, otherwise, the product will be corroision.


• Please read the instruction manual carefully before operation.


• For protection of batteries during transport and storage, lights bottom installed sleep switch, and is set to sleep mode, please check whether the lamp is in normal working condition before installation or testing, turn on the switch according to the instruction.


• the bottom of the switch control: Press 3 to 5 seconds, the light starts to sleep (stopped working); Press 1 to 2 seconds, the lights began to work); testing and operation of switches in the dark environments, or covered with black shade cloth in order to operate correctly.


• Any question in operation please contact our company
