HB-3000C Electronic Brinell hardness tester
1.The main features
automatic closed-loop force sensor control system
10 class Test force selection, 14 class test scale
robust construction, good rigidity, accurate, reliable, durable, high efficiency test
high precision degree microscope measurement system
testing process automated, unmanned operation error
The large LCD screen, menu, smart tips, easy to operate
accuracy in accordance with GB/T231.2 ISO6506-2
2. Range of applications
determination of the Brinell hardness of ferrous metals, non-ferrous metal and alloy bearing material
wide range of applications, especially suitable for parallel flat precision measurement
3. Main accessories
Big flat test bench: 1 set
Small flat test bench: 1 set
V-shaped test bench: 1 set
Steel ball indenter: Φ2.5 Φ5, Φ10 mm, each 1 set
Standard Brinell hardness blocks: 2 sets
20 times the reading microscope: 1 set
4. technical data
Measuring range: 4-650HBW |
Test force: 612.9, 980.7, 1225.9, 1838.8, 2451.8, 4903.5 |
| Specimen to allow a maximum height: 240 mm |
Indenter center to wall distance: 150 mm |
Power supply: 220 volts AC, 50/60 Hz |
Dimensions: 630 x 250 x 1000 mm |
Weight: approx. 210kg |
