  HB-3000C Electronic Brinell hardness tester





1.The main features
 automatic closed-loop force sensor control system
  10 class Test force selection, 14 class test scale
 robust construction, good rigidity, accurate, reliable, durable, high efficiency test
 high precision degree microscope measurement system
 testing process automated, unmanned operation error
 The large LCD screen, menu, smart tips, easy to operate
 accuracy in accordance with GB/T231.2 ISO6506-2



2. Range of applications
 determination of the Brinell hardness of ferrous metals, non-ferrous metal and alloy bearing material
 wide range of applications, especially suitable for parallel flat precision measurement



3. Main accessories
 Big flat test bench: 1 set
Small flat test bench: 1 set
V-shaped test bench: 1 set
Steel ball indenter: Φ2.5 Φ5, Φ10 mm, each 1 set
Standard Brinell hardness blocks: 2 sets
20 times the reading microscope: 1 set



4. technical data



Measuring range: 4-650HBW

Test force: 612.9, 980.7, 1225.9, 1838.8, 2451.8, 4903.5
          7355.3, 9807, 14710.5,29421 Newton
        (62.5, 100,125,187.5,250,500,750,1000
           1500, 3000 kilogram Force)

Specimen to allow a maximum height: 240 mm

 Indenter center to wall distance: 150 mm

Power supply: 220 volts AC, 50/60 Hz

  Dimensions: 630 x 250 x 1000 mm

Weight: approx. 210kg
