thrust bearing Shengyue all series good service

Thrust bearing

The thrust bearing is used specifically to withstand the axial force of the bearings, the bearings of the axis parallel to the direction of the force.

Thrust ball bearing

Thrust ball bearing is a separation of bearings, shaft ring, seat ring and cage, the ball of the component separation.

Thrust ball bearings can not limit the radial displacement of the axis, the speed limit is very low,

The one-way thrust ball bearings can only withstand a direction of axial load,

two-way thrust ball bearings can withstand axial load in both directions;

One-way thrust ball bearings can limit the shaft and the axial displacement of the direction of the shell,

two-way bearings can be restricted in both directions of the axial displacement.

Thrust roller bearings

Thrust roller bearings used for axial load mainly axial and radial joint load, radial load should not exceed 55% of the axial load.

Thrust bearing

Thrust ball bearing

Single row thrust ball bearings series:

Flat seat series: 511xx, 512xx, 513xx, 514xx, 29xx, 39xx.

Spherical seat series: 532xx, 533xx, 534xx.

Spherical seat series: 532xxU, 533xxU, 534xxU.

Double row thrust ball bearings of series:

Flat seat series: 522xx, 523xx, 524xx.

Spherical seat series: 542xx, 543xx, 544xx.

Spherical seat series: 542xxU, 543xxU, 544xxU.

Micro-and inch series:

The mini-series: Fxx-xx, such as the F10-18 10mm inner diameter, outer diameter 18mm.

Inch Series: Ox, such as O-4, the diameter size 4 × 25.4/8mm.

Thrust angular contact ball bearing

Thrust roller bearing

Thrust cylindrical roller bearing: Mainly used in oil drilling rigs, the system of iron and steel machinery.

81102 81103 81104 81105 81106 81107 81108 81109 81110 81112 81113 81114 81115 81116 81117 81118 81119 81120 81122 81124 81126 81128 81130 81132 81134 81136 81138 81140 81148 81152 81156 81160 81164 81168 81172 81176 81180 81184 81188 81192 81196 811/500 811/530 811/560 11/600 811/630 81206 81207 81208 81209 81210 51211 81212 81213 81314 81215 81216 81217 81218 81220 81222 81224 81226 81228 81230 81232 81234 81236 81238 81240 81244 81248 81252 81256 81260 81264 81268 81272 81276 81280 81284 81288 81292 81296 81140/YA,89448,81192,812/500,872/530,812/560,817/600,872/670,871/710,871/710,891/800,871/850,972/900

Thrust Spherical Roller Bearing: Mainly used in hydroelectric generators, vertical motors, ship propeller shaft, tower cranes, extruders .

Thrust tapered roller bearing: Main purposes: one-way: crane hooks, oil rig swivel. Two-way: rolling mill roll neck.

91236	19236	180×250×56	-
99246	9019426	130×270×85	28.5
99248	9019428	140×280×85	-
99436Q1	9019436Q	180×360×109	-
99440	9019440	200×400×122	85
99440Q1	9019440q	200×400×122	-
99448	9019448	240×440×122	-
99452	9019452	260×480×132	111
99456	90019456	280×520×145	143
99456M	9019456h	280×520×145	151
99456Q1	9019456Q	280×520×145	-
99464	9019464	320×580×155	185
99468	9019468	340×620×170	-
99476	9019476	380×670×175	274
91742X1	19742F	210×458.1×122	117.33
91742	19742L	210×460×122	107
91742X2	19742	210×460×150	137
91746	19946H	230×480×105	81.19
917/234.95Q1	19947Q	234.95×546.1×127	171
91754	19954H	270×550×130	164

Our adventage:

1.Original bearing certificate of origin

2. In Shanghai, convenient transportation and timely delivery .

3.Large stock Model is complete

4.more years of export experience

5. Establish a good working relationship with a number of areas

main market: North America, South America, Eastern Europe,Southeast Asia,Africa,

Oceania , Mid East , Eastern Asia ,Western Europe.

6.Our brand: SHR

Other(price,packing,series and service)

Original packing

Payment: A:30% deposit By T/T, Western Union, Paypal, 70% before delivery.

B:100% L/C at sight

Production Lead time: 7~25days; If we have this item of your q’ty in stock , 2days delivery.

Sample off: free sample for customer quality checking.

MOQ:1 set Supply Ablility:100000 pcs/Month
