E430e 4U ENTERPRISE SHORT-DEPTH SERVER CHASSIS



Mustang stylish architecture of the front door design, with stable and low noise fans, in line with good ventilation and dust protection requirements, suitable for the server cooling environment, global quality assurance and warranty for three years. One of the advantages of this E430e server is that the depth is only 300mm, the front can be installed two 5.25" ODD devices, this space can also be equipped with a number of hotswap HDD mobile racks, also this chassis can also install one 3.5" or two 2.5" SSD/HDD. The sheet metal mechanism design using 1.2mm thickness SGCC ultra-high strength material, all sheet metal cut-off surface are smooth folding design to ensure free-damage to hands or fingers, the front of the security door design can also ensure data security, to avoid improper disc burning or USB drive replication data causing security vulnerabilities. In addition to the general standard 12" x 9.6" ATX motherboard, this model can also be installed MicroATX or Mini-ITX motherboard, suitable for a variety of system environments. In addition in the price also absolutely has the advantage of competition, welcome distribution from all over the world.








* Drive Space: two 5.25" ODD bay, one 3.5" FDD/HDD bay or two 2.5" SSD/HDD
* Standard with two USB 3.0 ports at front bezel (behind the front security door)

* Standard with one brand new 120mmx25mm intake fan at front (fan part# D12SM-12C)

* Standard with two brand new 60mmx25mm intake fans at front (fan part# D60SM-12C)

* Build-in two ABS screwless 80mmx25mm fan brackets at rear panel (fans are option)

* Compatible motherboard: ATX(12"x9.6"), MicroATX(9.6"x9.6"), Mini-ITX(6.7"x6.7")

8cm or 12cm~14cm fan version standard PS2 PSU compatible (depth at 140~200mm)

* Support SureStar R4S series 400W~500W PS2 Mini Redundant PS (depth 174mm)
* Support Zippy MRT & MRW series 300W~600W PS2 Mini Redundant PS (depth 185mm)
* Support SureStar R4B series 600W~800W PS2 Mini Redundant PS (depth 199mm)
* Support Zippy MRG series 500W~800W PS2 Mini Redundant PS (depth 200mm)

* Support 7 slot full height expansion cards (maximum available depth at 255mm)

* Standard paint: scratch-resistant black textured at front

Genesys Group branded server chassis in global 3 years warranty
* Chassis dimension: 19" x 4U x 300mm (11.81" deep)

Accessory pack: MB stand-off x2, #6 round x21, M3 countersunk x8, M3 truss x6, 2 keys
* Package: NW 7KGM, GW 9 KGM, 2.31 CUFT (45x56x26cm, durable box packed) #

* Note 1: Suggest to release the rear panel + PS2 PSU first during system integration

* Note 2: If the 7th slot installed with card, the front FDD/HDD bracket shall be uninstalled

* Note 3: If no any 5.25" ODD installed at front, max. CPU cooler height at 150mm

* Note 4: If one 5.25" ODD installed at front, max. CPU cooler height at 100mm

* Note 5: If all two 5.25" ODD installed at front, max. CPU cooler height at 50mm










e430e-frontop.jpge430e-front-open.jpge430e-left-door-open.jpge430e-left-door-top-open.jpge430e-left-rear-rps.jpge430e-left-rear-side.jpge430e-left-z.jpge430e-reartopen.jpge430e-right-door-top-open.jpge430e-right-side.jpge430e-right-z (1).jpg
