Яркая распродажа 230 В 350 Вт электрический нагревательный стержень резистивный нагреватель с фланцем
3,00 $ - 9,00 $
12 В Гибкая силиконовая резиновая Тепловая
- Категория: Heating Equipment >>>
- Поставщик: Yancheng Nice Electric Heating Equipment Co. Ltd.
Сохранить в закладки 62008731149:
Описание и отзывы
Характеристики
200 Degree 200x200mm 220v AC Silicone Rubber Heater Pad
Silicone rubber heater is a kind of thin film which heats upon electrified, in a standard thickness of 1.5mm, Adopting nickel chrome wires or 0.05 mm~0.10mm thick nickel chrome foils etched to some certain shapes, the heating component is wrapped with heat conducting and insulating materials on both sides, and completed in high-temperature die forming and aging heat treatment. It consists of high temperature resistance wire wound around a fiberglass core for added support and flexibility while still allowing for expansion and contraction during heat up and cool down. The element is laid out in a computer designed pattern to provide maximum heat transfer and temperature uniformity. After the element is laid out, it is vulcanized between two sheets of silicone rubber until they become one. The silicone rubber sheets also have a layer of fiberglass for added strength and tear resistance. The same vulcanization process is used to attach the power leads and cord sets to the heater windings.
Specification
Silicone rubber heater is a kind of thin film which heats upon electrified, in a standard thickness of 1.5mm, Adopting nickel chrome wires or 0.05 mm~0.10mm thick nickel chrome foils etched to some certain shapes, the heating component is wrapped with heat conducting and insulating materials on both sides, and completed in high-temperature die forming and aging heat treatment. It consists of high temperature resistance wire wound around a fiberglass core for added support and flexibility while still allowing for expansion and contraction during heat up and cool down. The element is laid out in a computer designed pattern to provide maximum heat transfer and temperature uniformity. After the element is laid out, it is vulcanized between two sheets of silicone rubber until they become one. The silicone rubber sheets also have a layer of fiberglass for added strength and tear resistance. The same vulcanization process is used to attach the power leads and cord sets to the heater windings.
Specification
Shape | Round,square, Rectangular (Customized) | Max Using Temperature | 250℃ | |||
Volt | 12v-480v | Withstand Voltage | 1.5KV | |||
Watt | 0.1-0.3w/cm2 | Power Deviation | ±5% | |||
Thickness | 1.5mm or customized | Insulation Resistance | ≥5MΩ | |||
Max Size | 3000x1200mm | Min Size | 20x20mm | |||
Heating Material:Etched Nickel Chrome Foil | ||||||
Power Lead Wire:Silicone Rubber,SJ Power Cord or Teflon Insulated Stranded Wire | ||||||
Silicone drum heater Size list
Volume | 200L | 200L | 20L | 20L | 100L |
OD(Oil Barrel) | 580mm | 580mm | 300mm | 300mm | 580mm |
Size | 250x1740mm | 125x1740mm | 200x860mm | 120x860mm | 250x1250mm |
Volt/Watt | 220v/2000w | 220v/1000w | 220v/800w | 220v/500w | 220v/1500w |
Weight(KG) | 1.4 | 1 | 0.8 | 0.7 | 1.2 |
Waterproof | IP68 | IP68 | IP68 | IP68 | IP68 |
Liquefied Gas Cylinder Heating Belt Size list
Capacity | 15KG | 15KG | 50KG |
Size | 100X970mm | 150X970mm | 120x1250mm |
Volt/Watt | 220v/300w | 220v/350w | 220v/400w |
Weight(KG) | 0.5 | 0.6 | 0.8 |
Product Show
Features
1.Low MOQ: It can meet your promotional business very well.
2.OEM Accepted : We can produce any your design as long as you provide us the drawing.
3.Good Service : We treat clients as friend.
4.Good Quality :We have strict quality control system .Good reputation in the foreigner market
5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract)
2.OEM Accepted : We can produce any your design as long as you provide us the drawing.
3.Good Service : We treat clients as friend.
4.Good Quality :We have strict quality control system .Good reputation in the foreigner market
5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract)
Company Information
Yancheng Nice Electric Heating Equipment Co.,Ltd,a professional manufacturer according to customers’ requirements,has advanced production lines,testing equipment and QC department to provide clients with high quality goods.In addition,an experienced R&D department and service team to give clients best heating solutions.
Our products have been exported to Europe,America,Asia,Mid East etc,more than 200 countries,and used widely in Plastic Machinery,Vacuum Packing,Petroleum Chemical Industry,Food,Industrial Furnaces and Autonmation etc.
Thank you for your patience and welcome your cooperation.
Our products have been exported to Europe,America,Asia,Mid East etc,more than 200 countries,and used widely in Plastic Machinery,Vacuum Packing,Petroleum Chemical Industry,Food,Industrial Furnaces and Autonmation etc.
Thank you for your patience and welcome your cooperation.
Exhibition
Delivery & Package
1.Delivery time
For samples,5 to 7 days after payment
For big quantity,negotiated time
2.Package
1pcs/1 plastic bag 10 pcs/1 paper box
For heavy products,wooden case
For samples,5 to 7 days after payment
For big quantity,negotiated time
2.Package
1pcs/1 plastic bag 10 pcs/1 paper box
For heavy products,wooden case
