ISO Tank Containers for H3BO3

CSC factory owned seven the most advanced production lines for tank truck, semi trailer, chemical corrosion-resistant rotational moulding, Dish heads, C3 ISO tank container, pressure vessel, dump truck. Covers an area of 60,000 square meters. The leading products are chemical liquid tank truck, fuel tanker truck, tank container, watering truck, garbage truck, fecal suction truck, sewage suction truck, bulk cement truck series, asphalt tanker truck, dumper truck series, aerial working truck series, fire-fighting truck series, refrigeration and van truck series, wrecker truck series, semi trailer series, storage tank and heads of tanks etc. 16 series with more than 500 types in total, annual production capacity of 8000 units.

We offer quick turn around time and ship worldwide. Batch exported to Vietnam, Libya, Afghanistan, Angola, Kenya, Cuba, Bolivia, etc. more than 50 countries and regions

We warmly welcome new and old friends come to visit our company. We will, in line with loyalty and the public, sincere cooperation with all customers, find mutually beneficial & win-win situation, seek common development.

Quotation Part 2

A, Design proposal of 20 feet tank container

Net capacity: not less than 20cubic; Shell of tank container Materials using Wisco Q235 High quality carbon steel 6mm;, baffle,

Two feed inlets,bigger manhole covers, 2 NOS. pressure vent valves( breather valve) , at the end of the bottom , DN80 dump valve(discharge valve). Screw of Openings and valves adopt stainless steel screw screws, single coaming board on the top of tank Molybdenum red reflective tape

Framework is made of High quality steel, each one ladder at back and forth. With two acid resistant tube, two 4kg fire extinguishers

SPECIAL TANK CONTAINER FOR CHEMICAL SOLUTION:

IMO1 TYPE TANK CONTAINER FOR HYDROFLUDRIC ACID -32%HCL SOLUTION 20feet
Ext. Length	6,058mm	Ext. Width	2,438mm
Ext. Height	2,591mm	M.G.W.	28,00 0Kgs
Tare	5,000Kgs	Max. Payload	23,000Kgs
Cubic Capacity	20 m³	Tank Design Standard	ASME-VIII-1&GB150-98
Max. Design Pressure	2.65bar	(ADR/AID) Calculated Pressure	10.0bar
Testing Pressure	4.0bar	Design Operating Temp.	-20 ~ +80°C
Lining	t=16mm PE	Material of Tank Body	Q235A+PE
Tank Body Dia.	2,000mm	Tank Body Thickness	6 .0mm
Manhole Dia.	500mm	Stacking	192,000kgs
Facilities
Charging Valve		Discharging Valve	ALL Plastic ball valve DN80
Air Inlet Valve		Pressure Relief Valve	relief valve

internal strengthen lozenge expanded metal mesh transition, Plastic-lining thickness 16mm anti corrosion transport Chemical liquid Like,HYDROFLUDRIC ACID HCI 32%,CAUSTIC SODA NaOH 32%,NaCl. NaClO etc.
