25 мм 110 160 250 270 600 630 1000 1200 5 6 7 8 12 14 дюймов дренаж воды Upvc ПВХ трубы от производителя цена
- Категория: Plastic Products >>>
- Поставщик: Henan Hesu Group Co. Ltd.
Сохранить в закладки 62013806679:
Описание и отзывы
Характеристики
315mm 600mm 5 inch 8 inch 12 inch diameter 18 inch 24 inch plastic Pvc UPvc Water Pipe prices list for water supply or drainage
Products Show
Product Name | Factory Outlet Large Diameter 315mm 350mm 400mm 600mm 630mm PVC Plastic Pipe Price |
Material | Polyvinyl chloride |
Color | White Grey or customized |
Standard | GB/T 5836.1-2006 |
Length | 4m 6m or as required |
Feature | corrosion resistance and pressure resistance |
Application | Water supply, irrigation and drainage |
(DIN Standard,DIN8061,DIN 8062 )UPVC Pressure pipe for water supply PVC Pipe Drinking Water | ||||||||||||||
nominal outside diameter dn | S series SDR series and nominal pressure | |||||||||||||
S16 | S12.5 | S10 | S8 | S6.3 | S5 | S4 | ||||||||
SDR33 | SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 | SDR9 | ||||||||
PN0.63 | PN0.8 | PN1.0 | PN1.25 | PN1.6 | PN2.0 | PN2.5 | ||||||||
nominal wall thickness en | ||||||||||||||
20 | - | - | - | - | - | 2.0 | 2.3 | |||||||
25 | - | - | - | - | 2.0 | 2.3 | 2.8 | |||||||
32 | - | - | - | 2.0 | 2.4 | 2.9 | 3.6 | |||||||
40 | - | - | 2.0 | 2.4 | 3.0 | 3.7 | 4.5 | |||||||
50 | - | 2.0 | 2.4 | 3.0 | 3.7 | 4.6 | 5.6 | |||||||
63 | 2.0 | 2.5 | 3.0 | 3.8 | 4.7 | 5.8 | 7.1 | |||||||
75 | 2.3 | 2.9 | 3.6 | 4.5 | 5.6 | 6.9 | 8.4 | |||||||
90 | 2.8 | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 | 10.1 | |||||||
110 | 2.7 | 3.4 | 4.2 | 5.3 | 6.6 | 8.1 | 10.0 | |||||||
125 | 3.1 | 3.9 | 4.8 | 6.0 | 7.4 | 9.2 | 11.4 | |||||||
140 | 3.5 | 4.3 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 | |||||||
160 | 4.0 | 4.9 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 | |||||||
180 | 4.4 | 5.5 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 | |||||||
200 | 4.9 | 6.2 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 | |||||||
225 | 5.5 | 6.9 | 8.6 | 10.8 | 13.4 | 16.6 | - | |||||||
250 | 6.2 | 7.7 | 9.6 | 11.9 | 14.8 | 18.4 | - | |||||||
280 | 6.9 | 8.6 | 10.7 | 13.4 | 16.6 | 20.6 | - | |||||||
315 | 7.7 | 9.7 | 12.1 | 15.0 | 18.7 | 23.2 | - | |||||||
355 | 8.7 | 10.9 | 13.6 | 16.9 | 21.1 | 26.1 | - | |||||||
400 | 9.8 | 12.3 | 15.3 | 19.1 | 23.7 | 29.4 | - | |||||||
450 | 11.0 | 13.8 | 17.2 | 21.5 | 26.7 | 33.1 | - | |||||||
500 | 12.3 | 15.3 | 19.1 | 23.9 | 29.7 | 36.8 | - | |||||||
560 | 13.7 | 17.2 | 21.4 | 26.7 | - | - | - | |||||||
630 | 15.4 | 19.3 | 24.1 | 30.0 | - | - | - | |||||||
710 | 17.4 | 21.8 | 27.2 | - | - | - | - | |||||||
800 | 19.6 | 24.5 | 30.6 | - | - | - | - | |||||||
900 | 22.0 | 27.6 | - | - | - | - | - | |||||||
1000 | 24.5 | 30.6 | - | - | - | - | - | |||||||
Note:Nominal wall thickness en will be subject to design stress σS12.5MPa | ||||||||||||||
Details Images
PVC pipes advantage
1) PVC pipe is low in wasted energy, it's 70 KJ/m3, steel is more than 4.5 times than PVC. It's fit the philosophy that advocating green earth and energy conservation.
2)Inside of PVC pipe is smooth, water rate is 0.009 faster than rough factor, but lower than other
material pipe. It can save about 20% electricity by using transfusion.
3) PVC pipe has good function of mechanics and stands corrosive nature, light and easy to install, don't need to maintain. The
usage life for at least 50 years, it's about 2.5 time than metal pipe.
4) PVC pipe can save 16-37% in installation and service fee than iron pipe. As conduit can save 30-33% than metal conduit. Using
in hot and cold water, can save 23-44% that use the same size of brass pipe.
5) Water dissolve teat approves that PVC pipe can not affect the water quality; it’s the best choice for the water..
1) PVC pipe is low in wasted energy, it's 70 KJ/m3, steel is more than 4.5 times than PVC. It's fit the philosophy that advocating green earth and energy conservation.
2)Inside of PVC pipe is smooth, water rate is 0.009 faster than rough factor, but lower than other
material pipe. It can save about 20% electricity by using transfusion.
3) PVC pipe has good function of mechanics and stands corrosive nature, light and easy to install, don't need to maintain. The
usage life for at least 50 years, it's about 2.5 time than metal pipe.
4) PVC pipe can save 16-37% in installation and service fee than iron pipe. As conduit can save 30-33% than metal conduit. Using
in hot and cold water, can save 23-44% that use the same size of brass pipe.
5) Water dissolve teat approves that PVC pipe can not affect the water quality; it’s the best choice for the water..
Application Field
Our Company
Our Exhibition
Packing & Delivery
Packing Details : pcs/package
Delivery Details : Within 15 days after payment
Delivery Details : Within 15 days after payment
Our Service
FAQ
Q: What is your MOQ?
A: As customer's request.
Q: Why choose us?
A: We are a professional and leader of HDPE pipe factory, we offer pipeline system one stop services with competitive price and fast delivery time, and we insure our quality is the second to none.
Q: How to buy the product?
A: Contact with us by email or by Trade Manager, and inform us which product and quantity that you need, we will contact
you immediately. More specify the information that you provided more faster and easier you will get the quotation.
Q: Can I make my own design and logo on the product?
A: Yes, we do OEM. Welcome partner from globally, we can make your product in China.
Q: What's the payment term?
A: Order amount <=1,000USD, 100% in advance.
Order amount>=1,000USD, 30% T/T in advance, balance before shipment.
Order amount>20,000USD, 30% T/T in advance, balance L/C at sight acceptable.
Order amount>100,000USD, 100% L/C at sight acceptable.
Q: Still have more questions?
A: Please use the table below and send your questions to us. Thank you.
