Product Description

TECHNICAL CHARACTERISTICS

Voltage Relay RN-116 is designed for turning off the 220 V, 50 Hz residential and industrial single-phase load with power of up to 3.5 kW (up to 16 A) at unallowable circuit voltage fluctuation with automatic reset (hereinafter referred to as AR) after circuit parameter recovery.

RN-116 indicates actual input voltage value, fault condition and output relay condition.

\t
Description
\t
Value
\t
Rated voltage, V
\t
240
\t
Rated voltage frequency, Hz
\t
47 – 65
\t
Adjustable settings ranges:
-\tMinimal voltage tripping threshold (Umin), V
-\tMaximal voltage tripping threshold (Umax), V
-\tAuto-reclosing time delay, sec
\t

160 – 220
230 – 280
5 –900
\t
Fixed tripping time delay when input voltage exceeds the minimal tripping threshold (Umin), sec
\t
12
\t
Fixed tripping time delay when input voltage exceeds the maximal tripping threshold (Umax), sec
\t
1
\t
Fixed tripping time delay in case of voltage decrease more than 60V than the adjusted minimal voltage tripping threshold (Umin), sec
\t
0,2
\t
Fixed tripping time delay in case of voltage increase more than 30V than the adjusted maximal voltage tripping threshold (Umax), sec
\t
0,2
\t
Maximal commutation current (active power load), A (not less than) AC-1 type
\t
32
\t
Accuracy for tripping basing the voltage level measurement, V
\t
< 3
\t
Minimal operation voltage level at which PH-102 will keep working, V Maximal operation voltage level at which PH-102 will keep working, V
\t
100
400
\t
Voltage hysteresis, V
\t
4
\t
Operational temperature range, С
\t
from -25 to + 45
\t
Storage temperature, С
\t
from -45 to + 70
\t
Total power consumption, mA
\t
< 15
\t
Commutation lifetime of the output contacts:
-\tunder 32A power load, times (not less than)
-\tunder 5A power load, times (not less than)
\t

100 000
1 000 000
\t
Outer dimensions, mm
\t
120 х 80 х 43
\t
Net weight, kg
\t
0,170
\t
Wall mounting in vertical position in order to read the digits of the front panel indicator

1-\ttricharged seven-segment indicator

2-\tload switch indicator

3-\tmaximum voltage adjustment

4-\tminimum voltage adjustment

5-\tAR time adjustment

6-\toutput contacts

7-\tinput contacts

Detailed Images
Packing & Delivery

Packing - cartone box

Delivery - 14 days

Our Company

The quality management system of development and production complies with the requirements of ISO 9001:2015
