Сверла из карбида вольфрама для сверления

Chip-free edges thanks to spurs

Super abrasion, high precision,light cutting and no burrs around hole side

Safe drilling thanks to centering point

Safe drilling thanks to centering point

Concentricity of drill is below 0.01mm

Chip-free edges thanks to spurs

Optimum chip evacuation thanks to plastic coating

Suitable for drilling wood, PVC and plastic

Super abrasion, high precision,light cutting and no burrs around hole side

The edge part formed in one piece by the full automatic digital control grinder.

Mianyang Yasen Hardware Tools Co.,Ltd. is a professional manufacturer specializing in the production of industrial-grade Woodworking Drill Bits, T.C.T Solid Carbide Straight Bits and Collets. CNC machining center adopts one-time molding technology to guaratee the higher procesion, more scientific drilling point design.

OEM

1. Professional research team and sales team.

2. We have our own factory.

3. All products are 100% tested working before sending to you .

4. Quick delivery.

Packaging Detail: plastic box inside, and carton outside.

Delivery Detail: Within 10 days after received the payment.

•  The phenomenon of edge collapse

1,Crossed blade is not sharp and the two crossed blade is unequal-high.

2, Center point of drill and shank concentricity are not meet the criteria.

3,The machine is on the condition of wrong spindle run- out.

4,The board processing (artifact) is on the move.

5,Spindle rotation and cutter speed is not match.

6,The adaptor concentricity is low and other technical data are not up to standard.

• The phenomenon of ellipse

1,The center point and the shank is misalignment,or the center point is not sharp.

2,The artifact is on the move during drilling.

3,Spindle rotation and tool feed speed is not match.

4,The adaptor concentricity is low and other technical data are not up to standard

5,The spindle of boring machine is loose or damaged.

• The phenomenon of smoke or burn

1,The blade edge is not sharp, the drill bit should be replaced.

2,Spiral groove (chip groove) is congestion that will lead to chip removal poorly.

3,Artifact (material) is humidity over limit or the glue quality is not good ( especially the fiber board and plywood )

4,The tool feed speed is not match with the material and the depth.

5,Choose the suitable drill bit type for processing materials.
