Сканер рентгеновской безопасности для багажа в аэропорту

Сохранить в закладки 62020975477:


Цена:6 200,00 $*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description


FA-XIS series is our most popular and widely deployed X-ray inspection system. Dual energy imaging provides automatic color coding of materials with different atomic numbers so that screeners can easily identify objects within the parcel. It offers a full range of options and excellent image quality.



Specifications:
Model
FA-XIS5030A
FA-XIS5030C
FA-XIS5536
FA-XIS6040
FA-XIS6550
Tunnel Size(mm)
505(W)x307(H)
505(W)x307(H)
555(W)x365(H)
555(W)x365(H)
655(W)x505(H)
Conveyor Speed
0.20m/s
Conveyor Height
730mm
730mm
745.5mm
645mm
645mm
Max Load
150kg(even distribution)
150kg(even distribution)
150kg(even distribution)
160kg(even distribution)
160kg(even distribution)
Wire Resolution
40AWG (0.0787mm of wire)> 44SWG
Spatial Resolution
HorizontalΦ1.0mm/ VerticalΦ1.0mm
Steel Penetration
10mm
38mm
38mm
38mm
38mm
Monitor
17-inch color monitor,resolution of 1280*1024
Anode Voltage
80Kv
140-160Kv
140-160Kv
140-160Kv
140-160Kv
Cooling/Run Cycle
Oil cooling /100%
Per-inspection Dose
<1.0μG y
Image Resolution
Organics:Orange                 Inorganic:Blue                  Mixture and Light Metal:Green
Selection and Enlargement
Arbitrary selection,1~32times enlargement, supporting continuous enlargement
Image Playback
50 checked images playback
Storage Capacity
At least 100000 images
Radiation Leaking Dose
Less than 1.0μGy /h(5cm away from shell ),Comply with all domestic and international health and radiation safety standards
Film Safety
In full compliance with the ASA/ISO1600  film safe standard
System Functions
High-density alarm,auxiliary examination of drugs and explosive,TIP(threat image projection);date/time display,baggage counter, user management,system timing, ray-beam timing, power on self-test,  image back-up and search,maintenance and
diagnosis, bi-directional scanning.
Optional Functions
video monitoring system/ LED( liquid crystal display)/energy-conservation and environmental-protection equipment / Electronic weighing system etc
Overall Dimension(mm)
1719(L)x761(W)x1183(H)
1719(L)x761(W)x1183(H)
1813(L)x855(W)x1270(H)
1915(L)x865(W)x1210(H)
2114(L)x955(W)x1310(H)
Weight
500kg
500kg
550kg
600kg
600kg
Storage Temperature
-40℃±3℃~+60℃±2℃/5℃~95% (No condensation of moisture)
Operation Temperature
0℃±3℃~+40℃±2℃/5℃~95% (No condensation of moisture)
Operation Voltage
AC220V(-15%~+10%) 50HZ±3HZ
Consumption
0.6KvA




Main Features

☆ Compact Design

☆ High Density Alarm

☆ Full Features

☆ Multi-language Support

☆ Extremely High Resolution

☆ Assist to detect drug and explosives



Products






Packing & Delivery






Case Reference




About Fanchi-tech




Shanghai Fanchi-tech Machinery Co., Ltd started its humble openings in 2013, believing that through superior product design and engineering the production of higher quality equipment with customer-satisfied service could be achieved. Our first-class devices and services have gained recognition and trust of our customers. Our commitment and determination in the pursuit of perfection can prove to everyone that we deserve the trust of our customers. Currently, we are an established supplier of a full range of Metal Detectors, Weight Grading/Checking System, X-ray Inspection System, Public Security Equipment, etc. Compared with other manufacturers and distributors, all our machines are implemented in accordance with the demands and requirements of our customers at a reasonable price.

We provide advice and assistance in the design and implementation of the entire line of quality control of the HACCP. All of our devices are featured at high quality, superior design and excellent performance. We're devoted to designing, producing, selling, servicing and continuously improving the following systems:

1. Public Security Equipment: X-ray Baggage Scanner, Walkthrough Metal Detector, Explosives Detector, etc;

2. Food Safety Inspection System: X-ray Inspection System, Metal Detector, Checkweigher, etc;

We always persist the principle of innovative technology, outstanding quality and quick response service. With the great effort of each stuff member, our products have been exported to more than 30 countries from all over of world , such as America, Canada, Italy, Spain, Poland, Australia, New Zealand, Russia ,Turkey, Mexico, Korea, Israel, South Africa, Egypt, India, etc.
