BTH-450GS+BM-500L Continuous automatic Side Sealers with intermittent cycle


1. Production Instruction:

This machine adopts advanced side sealing and reciprocating type horizontal sealing technology. Have continuous sealing actions. Servo control series could realize excellent shrink packaging in the condition of high efficiency. Servo motor controls the actions. During the high speed running procession the machine will act stable, reliable and make the products delivery smoothly during the continuous packaging to avoid the situation that products slide and displaced.

Automatic Grade: Automatic

Driven Type: Electric

Suitable shrink film: POF

Application: suitable for big size packing, no limit for length, width can be 400mm.



Continuous automatic Side Sealers with intermittent cycle

2. Technical Data:

Model

BTH-450GS

BM-500L

Max packing size

(L)No limited (W+H) ≤400mm (H) ≤150mm

(L)No limited x(W)450 x(H)250mm

Max sealing size

(L)No limited (W+H) ≤450mm

(L)1500 x (W)500 x (H)300mm

Packing Speed

60~120 packs/min

0-30m/min

Electric Supply & Power

220V/50Hz  5kw

380V/50Hz  16kw

Max Current

10A

32A

Air Pressure

6kg/cm3

/

Weight

1200kg

470kg

Overall Dimensions

(L)2610 x (W)1410 x (H)1300mm

(L)1800×(W)1100×(H)1300mm



3. Machine video:

Machine videohttps://youtu.be/8pnKNKOkbBg
company instructionhttps://youtu.be/IzQL3pPVG9o




For more details and video informarion of this Continuous automatic Side Sealers with intermittent cycle, please feel free to contact us.
