Мини портативная солнечная панель из эпоксидной смолы 0 35 Вт зарядное устройство ZW 8040 5.5V легкого кремниевого модуля солнечной панели

Сохранить в закладки 62041623083:


Цена:16,54 ₽ - 22,05 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики






11













Epoxy Resin Solar Panel 0.35W Mini Portable Solar Panels Charger ZW-8040-5.5V Customizable Solar Panel




































































































Model:



ZW-8040-5.5V



Brand:



Zhiwang



Size:



80x40x2.5mm



Battery:



11



Peak power:



0.36W



Max voltage:



5.5V



Max current:



67mA



Open voltage:



6.05V



Short current:



85mA



Weight:



15g



Raw Material:



Poly Mono Crystalline Silicon


or Mono Crystalline Silicon


Epoxy Adhesive


or PET


Printed Circuit Board (PCB)


Glass Fiber Material Base Plate


Customizable



Operating Temperature(°C)



-40°C ~ + 85°C



Maximum System Voltage



7V(UL)/10V(IEC) DC



Maximum Rated Current Series



1A



Standard Testing Conditions



AM1.5     E=1000W/m2     T=25℃      Luminous intensity: 38000Lux


Test ambient temperature 25 ° C ±2 ° C
The humidity of the test environment is 60%-70%
Light intensity 40*1000 LUX
The vertical distance of light is 30cm
Open-circuit test multimeter
Load the test dedicated test stand
Application battery charging
Storage environment 20cm above the ground;


Humidity of 60% 70%; The normal temperature



Operating temperature:



-40°C to +85°C



NOCT



48°C+/-2°C



Guaranteed



3 year:90% of its nominal power rating



Certificates



CE, RoHS, EMC



Current temperature coefficient



%/K



0.06+/-0.01



Voltage temperature coefficient



mV/K



-(78+/-10)



Power temperature coefficient



%/K



-(0.5+/-0.05)






Zhiwang New Energy's solar panel module with high efficiency solar PV module adopts the worlds highest efficiency cell with efficiency up to 21%, and efficiency of the module is 25%-30% higher than the traditional ones.
This cell's positive pole and the negative pole are on the same side, the cell's front side can absorb maximum sunlight, so that it can get the maximum power.





Features
1. High cell efficiency with quality silicon materials for long term output stability;
2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures;
3. Used in glass laminated solar panels high transmittance low iron tempered glass or with enhanced stiffness and impact resistance;
4. Epoxy resin sealant materials with high transparency, high hardness and high strength are used in epoxy resin sealant solar panels;
5. In PET semi-flexible solar panels, high light transmittance, high hardness and high strength PET surface materials are used.
6. Excellent electrical performance at high temperature and low irradiance;
7. Can be widely used in decorative lights, electric toys, electronics, gifts and other industries;
8. Voltage, power, material, size and shape can be customized;
9. The products are widely used in solar lighting, lamps, household electricity, transportation, communications, meteorology, construction and photovoltaic power stations and other fields.
10. High quality solar cell, high solar energy conversion efficiency, up to 35%.
11. Monocrystalline or polycrystalline silicon solar cells are available.
12. Transparent low iron tempered glass and anodized alumina frame used in glass laminated solar panels ensure the modules work in extreme outdoor environments.
13. Glass laminated solar panels have a service life of up to 15 years. PET solar panels have a service life of up to 5 years; Epoxy rubber solar panels have a service life of 1-3 years.
14. Strict quality control, in line with the highest international standards;
15. Two professional plants of Zhiwang New Energy manufacture world-class products in accordance with iso9001:2008 (Quality management system) certification;





Quality Assurance Test
Thermal cycling test (provided by the supplier of floor material and surface material)
Thermal shock test (provided by the supplier of floor material and surface material)
Heat/freeze and high humidity cycle test (provided by the supplier of floor material and surface material)
Electrical isolation test (laboratory simulation data)
Hail impact test (laboratory simulation data)
Mechanical, wind and torsional load tests (laboratory simulation data)
Salt spray test (provided by the supplier of floor materials and surface materials)
Light and water exposure tests (laboratory simulation data)
Wet CO2 / SO2 (laboratory simulation data)
Test ambient temperature 25 ° C ±2 ° C
The humidity of the test environment is 60%-70%
Light intensity 40*1000 LUX
The vertical distance of light is 30cm
Open-circuit test multimeter
Load the test dedicated test stand
Application battery charging
Storage environment 20cm above the ground; Humidity of 60% 70%; The normal temperature
Working environment -20℃ - +85℃





 .png


IMG_20210417_091821.jpgIMG_20210417_091823.jpgIMG_20210417_091830.jpgIMG_20210417_091855.jpgIMG_20210417_091912.jpgIMG_20210417_091932.jpg


Yuyao











Q. Are you a manufacturer or a trading company?


A. We are two factories in Yuyao,Zhejiang and Xuzhou, Jiangsu, with OEM& ODM& Customization available.


Q. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our Professional Solar Panel Manufacturer 0.35W Epoxy Resin Solar Panel ZW-8040-5.5V sample.


Q. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q. What is your terms of delivery?
A: EXW, FOB, CIF. And other accepted payment method.
Q. How about your delivery time?
A: Generally, it will take 15 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your Professional Solar Panel Manufacturer 0.35W Epoxy Resin Solar Panel ZW-8040-5.5V order.
Q. Can you produce according to the samples?
A: Yes, we can produce by your Professional Solar Panel Manufacturer 0.35W Epoxy Resin Solar Panel ZW-8040-5.5V samples or technical drawings. We can build the molds and fixtures.
Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery Professional Solar Panel Manufacturer 0.35W Epoxy Resin Solar Panel ZW-8040-5.5V.


Q.How many years for warranty?


 A: Our warranty is 3 -5 years for our Professional Solar Panel Manufacturer 0.35W Epoxy Resin Solar Panel ZW-8040-5.5V.
