6 12 единиц Cdv MPV SUV гидравлический фургон двухуровневый Автомобильный перевозчик полуприцеп

TRI-Axle Double Tyre Car Carrier Semi-Trailer

(Three) Overall size: about 18005x2500x3886mm
(Four) Weight
(1) Complete vehicle kerb mass: 12300kgs
(2) Capacity load: 15000kgs
(3) Total weight: 27300kgs
(Five) Structural design: Frame structure
(Six) Loading capacity: The upper and lower platforms can load different cars (see the drawing)
(Seven) Hydraulic lifting system: The upper platform is divided into three parts, the upper platform in the rear deck is using two
pairs of hydraulic oil cylinders to control lifting, other platforms using chain hoist to control lifting, mechanical manual valve.
(Eight) Running gear
(1) Axle: Two unit of 11.5 tons axles FUWA
(2) Suspension system: FUWA two axle leaf spring suspension system,
leaf spring 4x20x90mm.
(3) Wheel rim: 6.75-17.5 9 pcs
(4) Tire: 235/75R17.5×9 (Spare tire included)
(Nine) Kingpin: 2” Bolted type JOST
(Ten) Landing gear: Fold landing gear
(Eleven) Brake system: Double pipe line air brake, WABCO brake valve, the front axle 30” air chamber, the last axle 30/30” air chamber
(Twelve) Electrical system: 24V, seven core socket, lights accord to standard in China.
(Thirteen) Others
(1) Chain hoist: 2 pcs
(2) Binding tools: 28 units (include chocks 28 pcs, binding belt 28 pcs)
(3) Spare tire bracket: 2 units
(4) Tool box: 1 unit
(5) One set of driver’s tool: 1 Gudgeon sleeve, 1 Cranking Bar , 1 Tire spanner
(6) 450L steel water tank and tyre water spraying device as optional
(Fourteen) Surface treatment
(1) Treatment before painting: Shot blasting for complete semi-trailer
(2) Painting: prime coat and final coat, color according to customer’s requirement.

1. Payment:  Deposit , 1 year balance credit after the B/L date.

2. Assemble :  We assble the trailer on your company.

3. Working time :  Our team working in 24 hours, we copy with all of your questions and after service.

CIMIC Container and trailer has longest history. Businesses covering the manufacture of dry cargo container, refrigerated container and special container as well as the semi trailer. Its annual production capacity of containers and trailers exceeds 2.4 million

1.  Design code and certificates

ASME,GB,ISO,CE,ADR,BV,DNV

2.  Productivity

100units per day

3.  Logo

Design and painting as your request

4.Payment

50% deposit , 50% before shipment

5. Guarantee

Five (5) years and be based on standard “RE 3” of the “European degree of rusting standards”. Normal wear/tear, or corrosion caused by fish oil, animal and vegetable oils, strong solvents, impact and accident is excluded.The warranty shall be applied faults or failures affecting more than 10% of the painted surface.

Decal guarantee   Seven (7) years.
