Модал шейкер

Name: Модал шейкер
SKU: 62047925024
Price: 1 074,00 $ USD
Availability: InStock

Цена:1 074,00 $*

Количество:

Modal Shaker (100N)

Features

Small size, light weight
For the environmental vibration and fatigue measurement of small and medium sized parts and instruments
Applied in testing the dynamic response, resonance frequency and mechanical impedance of small and medium sized structure
Wide frequency range, high output efficiency
Reasonable structure, high reliability

Specifications

Modal Shakers/Small Vibrators

Model	JZK-2	JZK-5	JZK-10	JZK-20	JZK-40	JZK-50	JZK-70	JZK-100	JZK-5T	JZK-30T
Rated peak force (N)	≥20	≥50	≥100	≥200	≥400	≥500	≥700	≥1000	≥50	≥300
Max. Rated Travel (mm)	± 3	± 7.5	± 10	± 10	± 10	± 10	± 12.5	± 15	± 5	±7.5
Max. Acceleration g	5	7	10	25	48.5	49.5	45.5	45	20	50
Maximum Input Current(Arms)	≤2	≤7	≤10	≤14	≤28	≤30	≤25	≤30	≤7	≤25
Frequency Range (Hz)	20HZ-6k	DC-3k	DC-2k	DC-2k	DC-2k	DC-2k	DC-1.5k	DC-1k	5-10k	5-5k
First Order Resonance Frequency (Hz)	40Hz	20Hz	20Hz	20Hz	15Hz	15Hz	10Hz	10Hz	40Hz	20 Hz
DC Coil Resistance	1.7Ω	0.7Ω	0.7Ω	0.7Ω	0.6Ω	0.6Ω	0.9Ω	0.6Ω	0.6Ω	0.6Ω
Force Constant (N/A)	8	7.2	10	14.3	11.3	16.7	28	33.4	7.2	12
Effective Moving Mass(Kg)	0.1	0.22	0.35	0.56	0.85	1.05	1.54	2.2	0.25	0.62
Dimensions (mm)	Φ78 × 112	Φ138 × 160	Φ158 × 190	Φ180 × 244	Φ190 × 345	Φ240 × 345	Φ280 × 385	Φ280 × 375	Φ138 ×165	Φ180 × 224
Mounting Hole(mm)	80×80 /4-Φ7	150×128 /4-Φ8	172×148 /4-Φ8	200×160 /4-Φ10	180×150 /4-Φ10	180×150 /4-Φ10	250×210 /4-Φ13	250×210 /4-Φ13	150×128 /4-Φ8	200×160 /4-Φ10
Wight(Kg)	2.9	8.1	15	17.5	38.5	38.5	68	68	8.5	25
Output Type	Mandril	Mandril	Mandril	Mandril	Mandril	Mandril	Table Φ80	Table Φ80	Table Φ60	Table Φ80
Connection Type	M5	M5	M5	M5	M5	M5	M5/M8	M5/M8	M5	M5
Recommended Amplifier	YE5871A	YE5871A	YE5872A	YE5873A	YE5874A	YE5874A	YE5874A	YE5878	YE5871A	YE5873A

Note: Table, Mounting type, small vibrators (JZK-100T, JZK-200T) can be customized.
