Hot Products KSD301 Black Bimetal Welding Machine Thermostat Switch

Сохранить в закладки 62069995519:


Цена:0,20-0,26 $*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description


 (1)93 (1)


















































































Use



Temperature control/Overheat protection



Appliance



KSD301 series is in wide use in a great variety of home appliances, such as coffee maker, water dispenser, toaster, microwave oven, rice cooker, dryer, steam iron ,tea pot ,water heater and portable icebox etc.,



Reset type



Auto/Manual reset



Base material



Bakelite/Ceramic base



Amperage



5A/10A/16A



Max. Operating Temperature



270°C



Differential



Temperture Differential :5-200℃(15℃ Standard)






Tolerance



Operating Temp. ±2-10℃











Contact material



Silver/Gold



Dielectric Strength



Parts between electriferous components and non-electriferous ones can bear 1500V 50Hz AC current, which is nearly sine wave, for one minute as bearing test. Resulted no breakdown, no flashover.



Insulation


Resistance



With a DC 500V megger, borne DC 500V, the tested value is over 100MW.



Resistance


Between Terminals



Below 50mW



Temperature


characteristics:



Normal type: OFF temperature higher than ON temperature.(Normal close)


One-shot type: The thermostat switches on at room temperature and it won’t be able to reset after switching off.



Maximum


ambient


temperature






300°C



Diameter of


bimetal disc



F12.8mm(1/2″)



Approvals



UL//TUV/CQC /ROHS/REACH



Terminal type



Customized (Refer to our specification)



Cover/Bracket



Customized (Refer to our specification)



 (3)


 (5)





About us


 (6)Foshan Kehua Electric Appliance Co.,Ltd established in 2010 .professional manufacturer engaged in the research, development, production, sale and service of KSD301 series bimetal disc thermostat . We are located in Foshan with convenient transportation access. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. In recent years, our company has introduced a series of advanced equipment including Automatic Bimetal Disc Forming, Bimetal Disc Inspecting, Automatic Spring Riveting, Automatic Molding, Full-automatic riveting silver machine,Endurance Lab,Inspection temperture machine,Finished product temperture sorting machine ect. In addition, we through the ISO9001: 2015 quality system certification, UL Certification , TUV safety certification , SGS environmental certification , CB certification and CQC safety certification.





Kehua always adhere to the people-oriented concept , with numbers of industry veteran engineers , first-class management talent , improve the management mechanism .providing high-precision, safe and reliable bimetal thermostats for many world-famous companies and all product working life up to 100,000 times.

 (7) (8) (9)





Hot Products


















Payment method


 (11)





FAQ


-(12)_011.What's your application for thermostat?
   Such as coffee machine;water dispenser;boiler ;oven;bottle sterilizer ect



2.Bimetal Thermostat Terminal and bracket can be customized as your request.
   Please share a picture or drawing for our reference of the type you use it before ,or please refer to our website.



3. Is there any certificate required?
    Our thermostat have passed a series safety certifications.such as UL.TUV.DVE,CQC,CB.CQM,


SGS .ROHS ,REACH ect .Should you have any interest, please contact us for possible deal, thanks!
