Заводская цена Лидер продаж Концевая фреза R0.3x50L 2F HRC60 для обработки с ЧПУ
- Категория: >>>
- Поставщик: Shenzhen Bwin Precision Tools Co. Ltd.
Сохранить в закладки 62076893006:
Описание и отзывы
Характеристики
1.Fully enables running at rough machining parameters, resulting in finish surface quality.
2.Excellent performance in machining titanium, stainless steel and high temperature alloys.
3.The coating provides longer tool-life or increased cutting-values.
4.Suitable for all types of steel or metal.
Product Name | Hot sale high quality use for Steel R0.3x50L-2F HRC60 Mocro Ball Nose End Mill |
Material | Tungsten Carbide |
Coating | TiSiN |
Standard | ISO |
Size | R0.3x50L-2F |
HRC | HRC60 |
OEM | Supply |
Use for | Pre-hardened Steel, Stainless steel, Die steel, cast iron, Nickel etc |
Products Show
![]()
![]()
Super Raw Material
Item Grade | HRC45 (YG10X ) | HRC55 (YL10.2 & WF25) | HRC60 (Germany K44 &K40) | HRC65 (Sandvik H10F) |
Details | Grain size 0.7um Co10% Flexural strength 3320N/mm2 | Grain size 0.6um Co10% Flexural strength 4000N/mm2 | Grain size 0.5um Co12% Flexural strength 4300N/mm2 | Grain size 0.5um Co10% Flexural strength 4300N/mm2 |
Super Coating
Coating Classifying and Advantage | ||||||||||
Item | Coating Type | AlTin | TiAlN | TiSiN | Naco | |||||
Characteristic | Hardness(HV) | 3300 | 2800 | 4300 | 42(GPA) | |||||
Thickness(UM) | 2.5-3 | 2.5-3 | 3 | 3 | ||||||
Oxidation Temp.(°C) | 900 | 800 | 1000 | 1200 | ||||||
Friction Coefficient | 0.35 | 0.3 | 0.25 | 0.4 | ||||||
Color | Black | Bronze | Bronze and gold | Blue | ||||||
Advantages | High heat stability | Normally cutting | Suitable for heavy cutting, and high hardness cutting | For high precision cutting | ||||||
Suitable for high speed, dry cutting | Suitable for cutting mould steel, stainless steel | Suitable for high hardness cutting, mould steel processing | ||||||||
Most suitable for carbide cutting tools, turning insert | ||||||||||
Specification | Flute Dia(φ) | Flute Length (C) | Shank Dia(D) | Overall Length(L) |
Φ1x3Cx4x50L | 1.0 | 3 | 4 | 50 |
Φ2x6Cx4x50L | 2.0 | 6 | 4 | 50 |
Φ3x8Cx4x50L | 3.0 | 8 | 4 | 50 |
Φ4x10Cx4x50L | 4.0 | 10 | 4 | 50 |
Φ5x13Cx6x50L | 5.0 | 13 | 6 | 50 |
Φ6x15Cx6x50L | 6.0 | 15 | 6 | 50 |
Φ8x20Cx8x60L | 8.0 | 20 | 8 | 60 |
Φ6x20Cx6x75L | 6.0 | 20 | 6 | 75 |
Φ8x25Cx8x75L | 8.0 | 25 | 8 | 75 |
Φ10x25Cx10x75L | 10.0 | 25 | 10 | 75 |
Φ12x30Cx12x75L | 12.0 | 30 | 12 | 75 |
Φ10x40Cx10x100L | 10.0 | 40 | 10 | 100 |
Φ12x45Cx12x100L | 12.0 | 45 | 12 | 100 |
Φ14x40Cx14x100L | 14.0 | 40 | 14 | 100 |
Φ16x40Cx16x100L | 16.0 | 40 | 16 | 100 |
Φ18x40Cx18x100L | 18.0 | 40 | 18 | 100 |
Φ20x45Cx20x100L | 20.0 | 45 | 20 | 100 |
