Нагревательный комплект с использованием нагревателя 1 5 кВт для медной трубки

Описание и отзывы

Характеристики

DW-1.5KW Series Portable Induction Heater

Heat practically any electrically conductive material: copper, aluminum, steel, stainless steel, titanium, brass, etc

Equipment Main Features and Functions

DW-1.5KW Portable Induction Heater is one kind of portable and mobile induction heater. To heat different kind of work-pieces, a wide range of coils can be used without changing the system’s set-up—simply change the coil and keep on working.

Can be used for heating and annealing various material,such as steel and copper, can also heat and anneal different kind of products,such as steel round rod and flat sheet,copper and brass tube,bolts,nuts,shafts,bearings,round steel,sheet,and so on.

Especially used for soldering and brazing the copper tube when install the air condition,no need to use the gas fire anymore.

Main Technical Parameters

Model No. DW-1.5KW

Product Quality   Premium

Protection Level IP22

Product certification: CE(EMC,LVD),CCC,Rohs

Input Voltage: 220V/110V,  AC,  50/60Hz

Max Output Power :  2KW

Stable Output Power: 1.5KW

Output Working Frequency: 18-60kHz

Standard Induction Cable Length: 2Meter

(Length Customized,)

Built-in Water Tank Volume : 3.10Liter

(can contact bigger external water water system,)

 Plug Type H Type,B Type,G Type,E Type

1) Attach a coil (don't need any tape),

2) Connect supply voltage,

3) Add cooling water. In our machine with closed cooling systems.

4) Set power outputs

5) Handheld transformers feature on/off .

6)Accurately regulate power by pressing the trigger.

7)Induction heating requires a minimum of 3 mm from the workpiece
