Дуговых выключатель TM80D LV429031 магнитно термический TM D 3P3D для NSX NS160 250 400A туда и обратно блок TMD 80 A 3 канальный 3d

Дуговых выключатель TM80D LV429031 магнитно термический TM D 3P3D для NSX NS160 250 400A туда и обратно блок TMD 80 A 3 канальный 3d

Категория: >>>
Поставщик: Simplybuy (shanghai) Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Arc fault breaker TM80D LV429031 Thermal-magnetic TM-D 3P3D for NSX NS160 250 400A Trip unit - TMD - 80 A - 3 poles 3d

Main

range of product	NSX100...250
product or component type	Trip unit
range compatibility	Compact NSX100 Compact NSX160 Compact NSX250
device application	Distribution
poles description	3P
protected poles description	3t
network type	AC
network frequency	50/60 Hz
trip unit name	TM-D
trip unit technology	Thermal-magnetic
trip unit protection functions	LI
trip unit rating	80 A 40 °C
protection type	Overload protection (thermal) L Short-circuit protection (magnetic) I

Complementary

mounting mode	Fixed
[Ue] rated operational voltage	690 V AC 50/60 Hz
long time pick-up adjustment type Ir	Adjustable
[Ir] long time pick-up adjustment range	0.7...1 x In
long time delay adjustment type	Fixed
[tr] long-time delay adjustment range	120...400 s at 1.5 x In 15 s at 6 x Ir
short-time pick-up adjustment type Isd	Fixed
[Isd] short-time pick-up adjustment range	640
short-time delay adjustment type	Fixed

Environment

standards	UL 508 EN/IEC 60947-2
product certifications	CCC EAC Marine
IP degree of protection	IP40 conforming to IEC 60529
pollution degree	3 conforming to IEC 60947-1
ambient air temperature for operation	-25...70 °C
ambient air temperature for storage	-50...85 °C

Offer Sustainability

Sustainable offer status	Green Premium product
RoHS (date code: YYWW)	Schneider Electric declaration of conformity
REACh	Reference not containing SVHC above the threshold
Product environmental profile	Product Environmental Profile
Product end of life instructions	Need no specific recycling operations

Contractual warranty

Warranty period	18 months

Compact NS Moulded Case Circuit Breaker

Acti9 MCB

11111

sigma mcb iC65H 4P C63A we have large inventory

Multi9 C60H C65H MCB min circuit breaker Made in France

Compact NS Moulded Case Circuit Breaker


LV432756 -1

LV431629 -1.JPG

Compact NS Air Breaker NS630-NS1600H

MasterPact MT NW NT Air Breaker

Packaging & Shipping

Shipping Policy:

1.Most orders less than 70KG (150 lbs). will be shipped via Fedex ,DHL UPS,TNT .Our shipment account have the best discount price for express to Worldwide.

2.All bulky and overweight items we will advise be shipped by Air or by Sea . Once you place order , we will come out the shipment cost for you to confirm.

3.If you wish to have items shipped on your account or your forwarder, you must provide all account information and instructions at the time of sale. Packaging and handling costs may still apply.

We can accommodate shipments on just about any carrier, and we ship worldwide any corner .

Extra Packing service with Simplybuy

1. Drop shipping available

2.Overnight shipping available on most we stock items

3.Factory Original new Packaged reinforced with Simplybuy extra foam and bubble protection .

We care your goods as our kids and keep everything well to you hand .

Payment:

1.We mostly accept T/T wire transfer ,our bank account accept USD,EUR,CAD,GBP, AUD, JPY,RUB fast speed without bank fee.

2.We accepted methods of credit card including Visa, MasterCard, American Express (AMEX), Discover .

3.We accepted Paypal and Escrow .

4.We accepted L/C Letter Of Credit - $300.00 fee (MOQ of $10k required) .
