Product Description
XCMG XE470D 50 ton Used Excavator China Heavy Crawler machine with best price
XE470D hydraulic excavator is one of the leading models of large excavators launched by XCMG excavator department. The product integrates the valuable experience gained by XCMG from years of research and development of excavator products, and adopts advanced design and manufacturing methods. Meanwhile, the product adheres to the design concept of "high efficiency, high safety, low carbon and environmental protection", and has perfect mine operation ability.
1. Ecological and economical
* Professional customized engine greatly improves fuel economy.
* Hydraulic oil flow regeneration system ensures optimum machine performance.
* Independent cooling system automatically adjusts fan speed.
2. Multiple applications
* Different boom, arm and bucket combinations can adapt to as many working conditions as possible.
* Multi-functional intelligent work tool control system can meet different operating requirements such as digging, breaking and dismanting.
* Instantaneous pressurization function copes with complex working conditions.
3.Comfortable operating experience
* Air Conditioner and Heator ensure the appropriate temperature.
* Silicone rubber shock absorber is adopted in the cab.
* Air-suspending seat equipped with electric heating function.
* Integrated control panel and large display screen provide multiple information.
* ROPS and FOPS Cab can improve cab safety.
XE470D hydraulic excavator is one of the leading models of large excavators launched by XCMG excavator department. The product integrates the valuable experience gained by XCMG from years of research and development of excavator products, and adopts advanced design and manufacturing methods. Meanwhile, the product adheres to the design concept of "high efficiency, high safety, low carbon and environmental protection", and has perfect mine operation ability.
1. Ecological and economical
* Professional customized engine greatly improves fuel economy.
* Hydraulic oil flow regeneration system ensures optimum machine performance.
* Independent cooling system automatically adjusts fan speed.
2. Multiple applications
* Different boom, arm and bucket combinations can adapt to as many working conditions as possible.
* Multi-functional intelligent work tool control system can meet different operating requirements such as digging, breaking and dismanting.
* Instantaneous pressurization function copes with complex working conditions.
3.Comfortable operating experience
* Air Conditioner and Heator ensure the appropriate temperature.
* Silicone rubber shock absorber is adopted in the cab.
* Air-suspending seat equipped with electric heating function.
* Integrated control panel and large display screen provide multiple information.
* ROPS and FOPS Cab can improve cab safety.
Advantages and highlights:
1.Offer Test Report of Professional Institute.
2.Details Of Maintenance And Repair Items Included.
3.Price Concessions.
4.Official Factory Sourcing.
5.Reconditioning Directly From XCMG.
6.Vehicle Condition of Perfection.
7.XCMG Official Endorsement.
8.SGS Provides The Third-Party Inspection Certificate.
1.Offer Test Report of Professional Institute.
2.Details Of Maintenance And Repair Items Included.
3.Price Concessions.
4.Official Factory Sourcing.
5.Reconditioning Directly From XCMG.
6.Vehicle Condition of Perfection.
7.XCMG Official Endorsement.
8.SGS Provides The Third-Party Inspection Certificate.
Specification
Model | Unit | XE470D | ||
Operating weight | Kg | 46900 | ||
Bucket capacity | m³ | 2.2-2.5 | ||
Engine | Model engine | / | QSM11-335 | |
Injection | / | √ | ||
Four strokes | / | √ | ||
Water cooling | / | √ | ||
Turbo-charging | / | √ | ||
No. of cylinders | / | 6 | ||
Rated power/speed | kw/rpm | 274/1800 | ||
Maximum torque/speed | N.m/rpm | 1790/1400 | ||
Displacement | L | 11 | ||
Main performance | Travel speed | km/h | 5.4/3.2 | |
Swing speed | r/min | 9 | ||
Gradeability | ° | 35 | ||
Ground pressure | kPa | 83 | ||
Bucket digging force | kN | 287 | ||
Arm digging force | kN | 221 | ||
Maximum tractive force | kN | 338 | ||
Hydraulic system | Rated flow of main pump | L/min | 2×360 | |
Travel system pressure | MPa | 34.3 | ||
Swing system pressure | MPa | 28.4 | ||
Pilot system pressure | MPa | 3.9 | ||
Oil Capacity | Fuel tank capacity | L | 725 | |
Hydraulic tank capacity | L | 430 | ||
Engine oil capacity | L | 38 | ||
Appearance size | Overall length | mm | 11670 | |
Overall width | mm | 3582 | ||
Overall height | mm | 3890 | ||
Width of platform | mm | 2995 | ||
Total width of chassis | mm | 3582 | ||
Track shoe width | mm | 600 | ||
Wheel base of crawler | mm | 4292 | ||
Track gauge | mm | 2750 | ||
Counterweight clearance | mm | 1324 | ||
Min. ground clearance | mm | 519 | ||
Working range | Max. digging height | mm | 9855 | |
Max. dumping height | mm | 6890 | ||
Max. digging depth | mm | 7000 | ||
Max. vertical wall digging depth | mm | 4500 | ||
Max. digging radius | mm | 10855 | ||
Min. swing radius | mm | 4580 | ||
Standard | Length of boom | mm | 6670 | |
Length of arm | mm | 2900 | ||
Bucket capacity | m³ | 2.5 | ||
Product Show
