Литий ионный перезаряжаемый литиевый аккумулятор NMC 12 В 18650 3S1P 11 1 в 2000 мАч

Сохранить в закладки 62217804073:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики


Rechargeable Lithium ion Battery Pack 11.1V 2000mAh 22.2Wh



Battery specification:

No.ItemsSpecificationsRemark

1Nominal Capacity2000mAh0.2C Standard discharge

3Nominal Voltage11.1V

4Discharge end voltage9.0V

5Charge Voltage12.6V±0.03VBy standard charge method

6Standard charging method0.2C constant current,12.6V constant voltage charge to 12.6V,continue charging till current decline to≤0.01C

7Charge current0.2C400mAStandard charge

0.5C1000mARapid Charge

8Continous discharge current2000mAh

9Cell Internal Impedance≤200mΩInternal resistance measured at AC 1KHZafter 50% charge

10Maximum charge current1C2000mAcontinuous charge

11Maximum discharge current1C2000mA

12Operation Temperature and relative humidity RangeDischarge-20~60℃ 60±25%R.H.Charge at a very low temperature such as blew 0℃,will be get a lower capacity and reduce cycle life of the battery

Charge0~45℃ 60±25%R.H.

13Storage temperature for a long time‘-10~45℃
60±25%R.H.
Do not storage exceed half year. Must charge once when storage for half year. must charge the battery with protect circuit when storage for three months.



Li-ion Battery Applications

Monitoring units, electric clocks and watches, tracking units, hybrid cars, laptop computers, portable devices, power tool equipment, PDA and IC cards, remote control keys, digital cameras, bluetooth headsets, toys etc.


Li-ion Battery Features

High energy density, no memory effect, superior safety, flat discharge voltage, long life cycle of 500 times


Customize Any of The Following Battery Packs as Required
Can be customized according to the requirements of 3.7V, 7.4V, 11.1V, 14.8V, 18.5V, 22.2V, 25.9V, 36V, 48V, 60V, 72V

11.1v 2000.jpg
